OEM Hydraulic Sheet 24 Ton Excavator Pile Driver Avoid Oil Pollution
Hydraulic Press Driver Excavator Pile Hammer Driver OEM Service
Parameter
| Item | FB30 | FB40 |
| Eccentric Moment | 40Nm | 85Nm |
| Centrifugal Force | 300kN | 570kN |
| Amplitude | 6.8mm | 14mm |
| Frequency | 2800rpm | 2800rpm |
| Pressure | 240-260kg/cm2 | 240-260kg/cm2 |
| Oil Flow | 155-200L/min | 200-255L/min |
| Turning Angle | 360degree | 360degree |
| Package Size | hammer with clamp:1450mm*1550mm*1650mm | hammer with clamp:1650mm*1700mm*1950mm |
| vice arm: 2700mm*800mm*1200mm | vice arm: 3350mm*850mm*1350mm | |
| Total: 7.41cube meters | Total: 8.81cube meters | |
| Net Weight | hammer with clamp: 2000kg | hammer with clamp: 2800kg |
| vice arm: 500kg | vice arm: 650kg | |
| Total: 2500kg | Total: 3450kg | |
| Suitable excavator | 20-35tons | 30-50tons |
1, High quality material (Q345b) provide high steel toughness and good abrasive resistance.
2, Easy to install , easy to operate.
3, Imported Motor, good endurance, high rotate speed, big torque, provide higher and faster agitate strength.
4, Can deal with steel sheet pile ,concrete sheet pile, steel pipe, by different shape pile cap.
5, Can be single chuck , adjustable double chuck , and mounted on crane for larger operating range.
A. 7Days*24Hours after-sales service by email or phone.
B. Your inquiry will be replied in 24 hours during workdays.
C. Professional technical team with many year's experience at your service.
D. OEM ODM Service available.
E. Warranty: 6 months, beyond the warranty period, all spare parts offered to you with our cost price (not including freight cost).
A: Yes,our factory was established in 2010.
Q: Are you sure your product will fit my excavator?
A: Our equipments are suitable for most excavators. Show us your excavator model, we'll confirm the solution.
Q: How about your products warranty?
A: 12 months warranty for hydraulic breaker, beyond the warranty period.
Q: Can you produce according to customers' design?
A: Sure, OEM/ODM service available. We are professional manufacturer in Yantai.
Q: What's the MOQ and payment terms?
A: MOQ is 1set. Payment via T/T,L/C, Western Union accepted, other terms can be negotiated.
Q: How about delivery time?
A: 5-25 work days after the payment.
Q: How about the package?
A: Our equipments wrapped by stretch film, packed by pallet or polywood case; or as requested.
Q: Which country have you exported?
A: Saudi Arabia, America, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc.
