Blanched Inshell Peanut Color Sorter 4 Chute 256 Ejector
Peanut Color Sorter,Blanched Peanut Color Sorter,Inshell Peanut Color Sorter
Dream Plus peanut color sorter,as an intelligent machine, can sort moldy peanut kernel, the frozen kernel, peanut kernel with husk, detect and remove foreign materials like glass in the raw material. Dream Plus peanut color sorter always provides customers with intelligent,professional and comprehensive sorting solutions,such as peanut with black spot, peanut crack and single kernel peanut. By introducing innovative online detection technology to the peanut processing industry, We will lead the industry into a new and smart era.
Check the examples of color sorter as below:
Technical Parameter
| Model | 6SXM-256JM4 |
| Output(T/h) | 0.8~1.5 |
| Carryover Rate(Bad:Good) | >12.5:1 |
| Sorting Accuracy(%) | ≥99.99 |
| Voltage (V/Hz) | 220V 50HZ |
| Power Supply(Kw) | ≤2.6 |
| Pressure(Mpa) | 0.5-0.8 |
| Weight(Kg) | 1200(±5%) |
| Diamension(mm) | 1800*1620*2040 |
Main features:
1. Excellent sorting persormance: Advanced image acquisition system + intelligent
image processing algorithm + high quality ejection system=excellent output and
rejection;
2. RGB full color tri-chromatic CCD image acquisition system: Top industrial 5400 pixel
CCD high speed linear scan imaging sensor also first-class tailored camera lens for color
sorting with a precision identifying tiny defects till 0.01m2;
3. Super ease operation system: Simple optical system design and accurate in time auto
calibration system plus simplified GUI design help reduce complicacies of machine
commissioning and running, easy operation and maintenance secured;
4. Customized image processing algorithm: Intelligence algorithm integrating image
color difference and defect size difference
5. Long-life software upgrading for free
