D155A-2 Bulldozer Hydraulic Cylinder Rebuild Kits Fits Repair Kits 707-98-12460
Replacement Seal 707-98-12460 7079812460 Hydraulic Repair Seal Kits Fits D155A-2 Bulldozer Komatsu
| Product Name | Komatsu Bulldozer Cylinder Seal Kit |
| Model Number | Komatsu D155A-2, D155A-2A , D355A-3 |
| Place of Origin | China(Mainland) |
| Brand name | BULLDOG |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.) |
| Part Number | 707-98-12460 |
| Payment Terms | Western Union, L/C, T/T, Money Gram, D/A, D/P |
| Size | Standard size |
| Applicable Industries | Construction works, machinery repair shops, retail, other |
| CertifiCATEEion | ISO9001 |
| Condition | 100% new |
| CATEEegory | Seal kits |
| Warranty | Unavailable |
| OEM and ODM | Welcome |
| Feature | Oil & high pressure & high temperature resistant |
| Preservation Notice | Closed, dry and avoid the sun |
| AppliCATEEion | Komatsu bulldozers D155A-6, D155AX-6, D155AX-7 |
ClassifiCATEEion and function of hydraulic cylinder seal kit:
- Hydraulic cylinder seal kits are used to seal the gap between different parts of the hydraulic cylinder. Within the system, there are 2 main types of hydraulic seals:
- Dynamic seals: Designed to seal various parts in relative motion. They can be utilized in high pressure and even when rod and hydraulic cylinder seals are in reciprocal motion between the head and the connecting rod.
- Static seals: Our static seal kit seal parts that are not in relative motion. These are used in various loCATEEions as per the construction and look of the hydraulic cylinder. The connection rod and piston is the primary area where these seals are used.
- Parts On Group:
![]()
|
Pos. |
Part No | Qty | Parts name |
| 175-63-02180 | [1] | CYLINDER ASS'Y | |
| 1 | 175-63-49170 | [1] | BUSHING |
| 3 | 707-29-70360 | [1] | HEAD,CYLINDER |
| 4 | 707-51-35210 | [1] | PACKING,ROD (KIT) |
| 5 | 175-63-75190 | [1] | SEAL,DUST (KIT) |
| 6 | 07179-12047 | [1] | RING,SNAP |
| 7 | 07000-12065 | [1] | O-RING (KIT) |
| 8 | 07146-02066 | [1] | RING,BACK-UP (KIT) |
| 9 | 07000-02070 | [1] | O-RING (KIT) |
| 10 | 175-63-49420 | [1] | ROD,PISTON |
| 12 | 707-36-70930 | [1] | PISTON |
| 13 | 707-44-70070 | [1] | RING,PISTON (KIT) |
| 14 | 07156-00710 | [1] | RING,WEAR (KIT) |
| 15 | 01580-02419 | [1] | NUT |
| 16 | 07040-12012 | [2] | PLUG |
| 17 | 07002-02034 | [2] | O-RING |
| K | 707-98-12460 | [1] | SERVICE KIT |
Parts exploded view
More service models
| D65E-12 | |||||||
| LIFT | 14X-63-01063 | 65 mm | 95 mm | KOM-707-98-28600 | |||
| 14X-63-01063 | 65 mm | KOM-707-52-10660 | |||||
| LIFT (TRIMMING) | 14X-63-07011 | 65 mm | 95 mm | KOM-707-98-28600 | |||
| 14X-63-07011 | 65 mm | KOM-707-52-10660 | |||||
| 14X-63-07012 | 65 mm | 95 mm | KOM-707-98-28600 | ||||
| 14X-63-07012 | 65 mm | KOM-707-52-10660 | |||||
| RIPPER | 14X-63-01052 | 70 mm | 140 mm | KOM-707-98-52130 | |||
| 14X-63-01052 | 70 mm | KOM-707-52-10700 | |||||
| TILT | 14Y-63-01032 | 70 mm | 140 mm | KOM-707-98-52140 | |||
| 14Y-63-01033 | 70 mm | 140 mm | KOM-707-98-52140 | ||||
| 707-01-0C300 | 70 mm | 140 mm | KOM-707-98-52210 | ||||
| 707-01-0C301 | 70 mm | 140 mm | KOM-707-99-52160 | ||||
| TRIMMING LH | 14X-63-07030 | 55 mm | 120 mm | KOM-707-98-40020 | |||
| 14X-63-07030 | 55 mm | KOM-07177-05530 | |||||
| TRIMMING RH | 14X-63-07040 | 55 mm | 120 mm | KOM-707-98-40020 | |||
| 14X-63-07040 | 55 mm | KOM-07177-05530 | |||||
Company warehouse
FAQ
1. Q: Are you a manufacturer or trader?
A: We are both in manufacturer and trader, have more than 10 years
of industry experience.
2. Q: Can i make a small order first?
A: Yes, of course.
3. Q: If we let the product make a change of the size, can you offer the
seal kit for this size?
A: Yes, just send the machine model, part number and the change
of size to us, we can make it.
4. Q: Have you support the OEM or not?
A: Sure, we support the OEM,BULLDOG or as required.
5. Q: How can i pay the goods?
A: For the payment, we support the PayPal, Western Union, Money Gram, T/T in advance, L/C at sight, etc
6. Q: How to ship the products?
A: For the shipment, we support the DHL Fedex EMS UPS or by Air/ Sea., if you have the agent in china, we can contact your agent according to your request.
7. Q: What’s the delivery time?
A: The goods can be shipped at 2-5 working days after receiving payment.
