Optical Zoom 20X HDMI SDI USB Conference Camera Auto Focus

Price Negotiable
Price: Negotiable
MOQ: 1 piece
Delivery Time: 1-10 working days
Brand: Tongveo
Product Description

VHD20N built in 1/3 inch high quality, 2.38MP (16:9)CMOS sensor,  with Full Glass Lens Material. It has Crystal clear HD1080P image quality and  Sleek and intelligent design. It is equipped with 20X optical zoom with SDI, USB, HDMI interface.





Features:

* 20X optical zoom
* Sleek and intelligent design
* Crystal clear HD1080P image quality
* Preset: 9 via IR remote setting (256 via RS232)
* Wide field of view with no video distortion
* 1/3 inch high quality, 2.38MP (16:9)CMOS sensor
* Superior quality with Full Glass Lens Material
* HD-SDI, HDMI , USB Video Output
* Support ceiling mount, wall mount and tripod mount (Reverse mountable)
* 2D and 3D NR for best video quality in different lighting conditions
* Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control*
* Compatible with most leading video conferencing software and platform
* Utilizing belt drive technology the PTZ is ultra-quiet and fast, while being very smooth



Parameters:

Model No.
TEVO-VHD20N
Image Sensor
1/3 inch HD CMOS
Effective pixel
2.38 mega pixel(16:9)
Horizontal Resolution
1080P60/50/30/25, 1080I60/50/30/25, 720P 60/50
Focal length
F=4.7mm(wide)-94.0(tele)
Signal standard
NTSC/PAL
Zoom
20x zoom
Horizontal view angle
Near-end 55.5°~Far-end 3.0°
Gain control
Auto/manual
Focus
Auto/manual
SNR ratio
≥50dB
Shutter speed
1/1 sec to 1/10000s (22 steps)
Preset position
Remote-controller supports 9 presets,
PELCO Control Protocol supports 256 presets
Pan/Tilt movement range
Pan: 340°(Max Speed 80°/S), Tilt: 120°(Max Speed 60°/S)
Control terminal
RS-232, RS485
Control Protocol
VISCA, PELCO-D, PELCO-P (RS-232, RS485)
Video output
3G-SDI, DVI (convertible to HDMI)
Noise Reduction
2D/3D
Baud rate
2400/4800/9600/19200bps
Decoder
Built-in
Address Set
1~256
Installation
Support desktop, Tripod, Wall mount and Ceiling mount
