High Frequency Solar Power Inverter 3KW 230VAC Pure Sine Wave
MUST Solar Power Inverter 3KW 5.2KW 230VAC Off Grid High Frequency Pure Sine Wave
| MODEL | PV18-3024 PRO | PV18-5248 PRO |
|---|---|---|
| Nominal Battery System Voltage | 24VDC | 48VDC |
| INVERTER OUTPUT | ||
| Rated Power | 3000VA / 3000W | 5200VA / 5200W |
| Surge Power | 6000W | 10400W |
| Waveform | Pure sine wave | |
| AC Voltage Regulation (Batt.Mode) | 230VAC±5%(Setting) | |
| Inverter Efficiency(Peak) | 93% | |
| Transfer Time | 10ms (UPS / VDE4105) / 20ms (APL) | |
| AC INPUT | ||
| Voltage | 230VAC±5% | |
| Selectable Voltage Range | 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105) | |
| Frequency Range | 50Hz / 60Hz(Auto sensing) | |
| BATTERY | ||
| Normal voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27.4VDC | 54.8VDC |
| Overcharge Protection | 30VDC | 60VDC |
| SOLAR CHARGER & AC CHARGER | ||
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum PV current | 18A | |
| PV Array MPPT Voltage Range | 150~430 VDC | |
| Maximum Solar Charge Current | 80Amp | |
| Maximum AC Charge Current | 60Amp | |
| Maximum Charge Current | 80Amp | |
| MECHANICAL SPECIFICATIONS | ||
| Machine Dimensions (W*H*D)(mm) | 272*355*100 | 295*528*121 |
| Package Dimensions (W*H*D)(mm) | 540*395*241 | 628*425*251 |
| Net Weight(kg) | 11 | 14 |
| Gross Weight(kg) | 12 | 15 |
| OTHER | ||
| Humidity | 5% to 95% Relative humidity (Non-condensing) | |
| Operating Temperature | 0°C~50°C | |
| Storage Temperature | -15℃ ~60℃ | |
Q1: What is the MOQ for this model?
A1:100 pcs. We can also ship the goods in a week to customer when we have stock.
Q2: How would the goods be shipped?
A2: We ship goods by DHL, UPS, FedEx, TNT and by Sea normally.
Q3: How about the delivery time?
A3: 7 days for sample; 40-45 days for bulk order.
Q4: What is the warranty of this model?
A4: Three year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q6: What is the payment?
A6:T/T, Western Union, Ali Pay, LC are warmly welcomed.
