Howo New Chassis Sany Second Hand Truck 37 Meter For Construction

Price Negotiable

Price: Negotiable

MOQ: 1 Unit

Delivery Time: 7-20 Working Days

Brand: Sany

Product Description

37 Meter Howo New Chassis Sany Brand Second Hand Truck,For Construction

Main Parameters

Model		ZLJ5290THB
Pumping system	Maximum theoretical delivery (m3/h)	100/60
	Concrete maximum outlet pressure (MPa)	8/15
	Fixed work stress (MPa)	35
	Pumping frequency (min-1)	25/14
	Hopper volume (L)	550
	Feeding height (mm)	1540
	Hydraulic system type	open
	Distribution valve form	S valve
	Cylinder bore × stroke (mm)	Φ150×1650
	Concrete bore diameter × stroke (mm)	Φ230×1650
	Hydraulic oil cooling	Air cooled
	Recommended slump (cm)	12~23
	Maximum aggregate size (mm)	40
Boom	structure type	37X-4RZ
	Maximum fabric height (m)	36.5
	Maximum cloth radius (m)	32.15
	Maximum cloth depth (m)	24.95
	Swing angle	±270°
	Number of arms	5
	Arm length (mm)	7280/5920/5670/6880/6750
	Arm angle	90°/180°/180°/240°/195°
	Duct diameter (mm)	125
	End hose length (mm)	3000
	Boom minimum opening height (mm)	7790
	Leg span (front × back × portrait) (mm)	6190mm×7740mm×6780mm
Chassis and vehicle	Chassis model	Howo Brand
	Wheelbase (mm)	5200
	Engine maximum power (kW/(r/min))	228/2300
	Engine maximum torque N.m/(r/min)	1230 /(1200~1800)
	engine capacity cc	6870
	Fuel tank volume L	300
	Exhaust emission standard	Euro V
	Vehicle quality (kg)	28870
	Overall dimensions (length × width × height) mm	9840×2530×3905
other	Lubrication method	Energy-saving automatic lubrication
	Hydraulic tank volume L	630
	control method	Manual + remote
	Pump maximum pressure MPa	6
	Water tank capacity (L)	350
	Concrete pipe cleaning method	Washing/dry cleaning
