Description

 Fiber to the home (FTTH) infrastructures make network organizers adopt powerful management and planning systems, FTTH termination box is a small part of this system and provides a cost-effective solution for FTTH applications. FTTH Termination Box available for the distribution and terminal connection for various kinds of optical fiber system, Some are used for indoor cabling and others are designed to install on outdoor pole or wall mount use.They are of light and compact design, Mainly used in fiber optic drop cable, pigtails or splitters cablings in residential buildings area. Most of them are applied to wall mounted type. The capacity is optional, such as small single fiber distribution box, 2 ports, 4 ports, 6 ports, 8 ports, 12 ports, 16 ports, 24 ports or even high density fiber distribution requirements.
Type 86 information panel is also called optical board or information board. It is the termination for optical fiber user, specially designed to construct FTTH. It can be installed at the corridors and multi-media cases for optical fiber users. The methods of coldly-connected or hot-melted can be used to connect the optical ends, and transmit the light by the adapterd or end of fiber to the ONU of terminal user. The Products are in fine property, and universal for user. It is widely applied in FTTX, LAN, Cable TV, and other telecom systems.

Features :

1. Small size and light weight for easy installation
2. Double-layer design for easy installation and maintenance
3. Four cable entry, available from the top, bottom, right side into the line, easy to choose routing
4. Single-core, dual-core fiber adapter can choose
5. Using high-quality ABS material, with a certain fireproofing performance
6. With dust-proof device to prevent dust
7. With a logo bar, easy to manage number and maintain
8. Applicable with fiber optic cable or indoor cable
9. Adapter Type: SC, LC
