PC FTTH Fiber Optic Aerial Splice Enclosure 2.5kg 12 Core To 72 Core
FTTH 2 Inlets 2 Outlets Plastic Dome Type Vertical Pipeline Buried Duct Mounting Fiber Optical Splice Closure
Description:
FTTH 2 Inlets 2 Outlets Plastic Dome Type Vertical Pipeline Buried Duct Mounting Fiber Optical Splice Closure, also known as FTTH 2 Inlets 2 Outlets Plastic Dome Type Vertical Pipeline Buried Duct Mounting Fiber Optical Joint Box, is the place where the end of optical cable is connected. Then it is connected to optical switch through optical fiber jumper to prevent material aging caused by heat, cold, light, oxygen and microorganisms in nature.
Features:
Ageing resistance & ultraviolet radiation resistance
Advanced internal structure design
Easy and fast to fix fiber cable
The closure is spacious enough for winding and storing fibers
Grouping function: 2 inlet 2 outlet can meet most requirements
Splice tray: using cascading structure, no need to take other splice tray when do operation
Specification:
| Product name | Dome Type Vertical Fiber Optic Splice Box |
| Protection level | IP68 |
| Scope of application | 12 core to 72 core |
| Gross weight | 2.5 kg |
| Main material | PC |
| Scope of use | Outdoor Aerial Dome,Buried,pole mount type outdoor |
| Ambient temperature | - 40 °C ~ + 60 °C |
| Service life | ≥20 years |
| Application scope | FTTH FTTB FTTX Network |
| Atmospheric pressure | 70kPa~106kPa |
| Insulation resistance | >2*10MΩ/500V(pc) |
| Tensile strength | >1200N |
