Rigid Flexible Custom SMT PCBA Assembly 0.2mm Thickness 4 Mil
Price:
Negotiable (Depends on your gerber and bom)
MOQ:
1pcs
Delivery Time:
1-30days
Brand:
Leadsintec
Product Description
Rigid Flexible Custom SMT PCBA Assembly 0.2mm Thickness 4 Mil
SMT PCBA Assembly Pcb Pcba Circuit Board SMT Circuit Board Manufacturer Custom Electronic Assembly Pcb Pcba
Products Capability
| Items | PCB capacity |
| Product name | SMT circuit board manufacturer custom electronic assembly PCB PCB |
| Material | FR-4; High TG FR-4; Aluminum; CEM-1; CEM-3; Rogers, etc |
| PCB type | Rigid, flexible, rigid-flexible |
| Layer NO. | 1, 2, 4, 6, up to 24 layer |
| Shape | Rectangular, round, slots, cutouts, complex, irregular |
| Max PCB dimensions | 1200mm*600mm |
| Board Thickness | 0.2mm-4mm |
| Thickness Tolerance | ±10% |
| Min Hole Size | 0.1mm (4 mils) |
| Copper Thickness | 0.5 OZ-3OZ (18 um-385 um) |
| Copper Plating hole | 18um-30um |
| Min Trace Width | 0.075mm (3mil) |
| Min Space Width | 0.1mm (4 mils) |
| Surface finish | HASL, LF HASL, Imm Gold, Imm Silver, OSP, etc |
| Solder mask | Green, red, white, yellow, blue, black, orange, purple |
| Items | PCBA capacity |
| Product name | SMT circuit board manufacturer custom electronic assembly PCB PCBA |
| Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
| Testing on products | Testing jig/mold, X-ray Inspection, AOI Test, Functional test |
| Quantity | Min Quantity : 1pcs. Prototype, small order, mass order, all OK |
| Files needed | PCB : Gerber files(CAM, PCB, PCBDOC) |
| Components: Bill of Materials(BOM list) | |
| Assembly: Pick-N-Place file | |
| PCB Panel Size | Min size : 0.25*0.25 inches(6*6mm) |
| Max size : 1200*600mm | |
| Components details | Passive Down to 0201 size |
| BGA and VFBGA | |
| Leadless Chip Carriers/CSP | |
| Double-sided SMT Assembly | |
| Fine BGA Pitch to 0.2mm(8mil) | |
| BGA Repair and Reball | |
| Part Removal and Replacement | |
| Component package | Cut Tape, Tube, Reels, Loose Parts |
| PCB+ assembly process | Drilling-----Exposure-----Plating-----Etching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity |
Quality and Policy :
1.Continually improve our quality, efficiency, service to satisfy thecustomer's requirement.
Quality Specifications:
Quality System:
1. ISO-9001:2021 Quality System Standard
2. Quality Standard: IPC-610-F,
3. Soldering Standard: J-STD-001 class 1,2,3
4. ESD Standard: ESD-MIL-STD-1686
5. Workshop management:5S
6. FAI-first article inspection
7. In process visual inspection
8. AOI inspection
9. Machine calibration and preventative maintenance
10. ERP material and process management ( ERP=enterprise resource planning computer system)
.
What Can We Do?
• Components procurement, checking, replacement,or alternative parts
• Project development, electronic design, ID design, mechanic design, F/W
development App, web, cloud development, Suppliers and project management, etc.
• Certification LAB provided in the group
• Engineering service and technical support.
• Electronic products manufacturing(PCBA).
• Complete Unit assembly (Box build).
• Quality assurance
• Logistic arrange for import and export from China.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Northern Europe(40.00%),North America(10.00%),Western Europe(10.00%),Southern Europe(10.00%),Domestic Market(10.00%),South America(5.00%),Eastern Europe(5.00%),Africa(5.00%),Oceania(5.00%). There are total about 101-200 people in our office.
2. how can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
PCBA,PCB,Components
4. why should you buy from us, not from other suppliers?
10 years engineer support for RD, electronic SMD, DIP, package process Quality according to ISO9001 In house IPC-610-E process Very good communication and service support
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,CPT,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Cash,Escrow;
Language Spoken:English,Chinese
