PCB PRODUCTION CAPACITY
|
|
|
Finish type
|
Gold-plated, Immersion gold-plated, HALS finish, Flux., Carbon-bridge, Entek, Nickel plating
|
|
Base material
|
FR4, CEM-1, CEM-3, FR1, FR2, Aluminum metal substrate and Rogers
|
|
Base material thickness
|
0.4-2.4mm.
|
|
Copper foil thickness
|
18um(H/HOZ), 35um(1/1OZ), 70um(2/2OZ), 5OZ
|
|
Maximum-product board
|
500*700mm. For AL PCB: 500*1400mm
|
|
Minimum drilled hole size
|
0.075mm
|
|
Minimum track width/spacing
|
3mil
|
|
Average hole wall copper
|
Thickness for HAL board: ≥25um.Gold-finger plating: ≥0.1um
|
|
Solder mask ink
|
Photo cure ink, heat cure ink. UV ink
|
|
Outline tolerance
|
±0.1mm
|
|
Hole diameter tolerance/ Hole location tolerance
|
±0.076mm/±0.076mm
|
|
V-CUT tolerance
|
±0.1mm.
|
|
Wrap
|
According to the IPC-600F standard
|
|
Lead time
|
Single-sided: 2-3 working days; Double-sided: 3-4 working days; Multi-layer: 8-10 working days
|
|
PCBA MANUFACTURING CAPABILITY
|
|
|
PCB Layers
|
1 to 36 layers (standard)
|
|
PCB material/type
|
FR4, Aluminum, CEM1, Supper-thin PCB, FPC/Gold finger
|
|
Assembly service type
|
DIP/SMT or Mixed SMT & DIP
|
|
Copper thickness
|
0.5um-4um
|
|
Assembly surface finish
|
HASL,ENIG,OSP
|
|
PCB Dimension
|
600x1200mm
|
|
IC Pitch(min)
|
0.2mm
|
|
Chip Size(min)
|
0201
|
|
Leg distance(min)
|
0.3mm
|
|
BGA Size
|
8x6mm~55x55mm
|
|
SMT Efficiency
|
SOP/CSP/SSOP/PLCC/QFP/QFN/BGA/FBGA/u-BGA
|
|
u-BGA ball dia.
|
0.2mm
|
|
Required Docs for PCBA
|
Gerber file with BOM list & Pick-N-Place File(XYRS)
|
|
SMT speed
|
CHIP components SMT speed 0.3S/pcs, max speed 0.16S/pcs
|
What Can We Do?
our Service
1. Extensive Contract manufacturing services:
We do much more than PCB's-You can reduce your logistical and administrative overheads by employing Leadsintec as the single source for all the manufacturing services detailed below. Take a look through our services detailed below for more information.
1. SMT Assembly:
Leading-edge surface mount population technologies.
2. PTH Assembly:
RoHS compliant wave soldering & hand soldering capabilities.
3. PCB design:
Can provide circuit design & PCB layout support.
4. PCB Fabrication:
Provide us with your design files/Gerber files and we will produce your PCBs on-site here in our China manufacturing facility.
5. Component procurement:
Take advantage of Leadsintec's purchasing & material control expertise.
6. Cable Assembly:
While we make your PCBs we can also be making your cables.
7. Product Assembly:
Leadsintec offers total turnkey solutions including full product build.
8. Function Test & Inspection:
Leadsintec offer test & inspection services on PCBs & assemblies ((X-ray, 3D Paste Thickness, ICT, AOI, and Functional tests)
