Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold plating
Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold Plating
Industrial PCB Assembly Custom 94v0 Fr4 PCBA Electronics Circuit Board Pcb Assembly
| NO. | Item | Specification |
| PCB Manufacturing Capabilities | ||
| 1 | PCB layers | 1 to 48 layers |
| 2 | PCB board material type | CEM-1,FR4,High-TG FR4,ALU,CEM-3,Rogers,HDI,etc. |
| 3 | Max dimension | 600 x 480mm |
| 4 | Min line width | 0.1mm |
| 5 | Min spacing | 0.1mm |
| 6 | Dimension tolerance | ±0.1mm |
| 7 | Min hole diameter | 0.2mm |
| 8 | Pcb board thickness coverage | 0.2 to 6.0mm |
| 9 | Min copper thickness in hole | 0.02mm |
| 10 | DK thickness | 0.08 to 6.0mm |
| 11 | NPTH size tolerance | ±0.025mm |
| 12 | PTH size tolerance | ±0.025mm |
| 13 | Dimension tolerance | ±0.1mm |
| 14 | Hole position tolerance | 0.075mm |
| 15 | Laser drill hole size | 0.1mm |
| 16 | Min soler mask | 0.01mm |
| 17 | Minimum size of solder mask separation ring | 0.05mm |
| 18 | Max board twist and wrap | ≤1% |
| 19 | Finished hole diameter | 0.2 to 6.0mm |
| 20 | Flame resistance | 94V-0 |
| 21 | Impedance control tolerance | ±5% |
| 22 | Outer layer copper thickness | 8.75 to 175um |
| 23 | Inner layer copper thickness | 17.5 to 175um |
| 24 | Solder mask type | Blue, Green, Black,Yellow, Red, White |
| 25 | Surface finish | ENIG, Gold plating, Immersion silver, Immersion tin, etc. |
| 26 | Certificate | ISO9001, ISO14001, ISO14969 |
Company Introduction
Leadsintec was founded in 2004, which is a factory that is committed to providing customers with one-stop services such as component purchasing, SMT processing, test assembly, etc. The company has multiple high-end SMT production lines and test assembly lines with high quality Stable and fast delivery advantages; provide satisfying one-stop hardware innovative manufacturing solutions for customers in wireless communication, AI intelligent hardware, industrial automation, medical, military, and other fields! And has been selected as the outstanding supplier of the year by leading domestic and foreign companies!
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Northern Europe(40.00%),North America(10.00%),Western Europe(10.00%),Southern Europe(10.00%),Domestic Market(10.00%),South America(5.00%),Eastern Europe(5.00%),Africa(5.00%),Oceania(5.00%). There are total about 101-200 people in our office.
2. how can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3. what can you buy from us?
PCBA,PCB,Components
4. why should you buy from us, not from other suppliers?
10 years engineer support for RD, electronic SMD, DIP, package process Quality according to ISO9001 In house IPC-610-E process Very good communication and service support
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,CPT,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Cash,Escrow;
Language Spoken:English,Chinese
