Double Sided Prototype Medical PCB Assembly Lead Free High Tg FR4
Double Sided Prototype Medical PCB Assembly Lead Free High Tg FR4
One Stop One Stop Multi-Layer Double Sided Prototype PCB AssemblyMulti Layer Double Sided Prototype PCB Assembly Service
Our Advantages:
1. Program and functional test and package by Free.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.
4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001,ISO13485,TS16949
5. The warranty period for PCBA: 2 years.
6. About Factory: 13 SMT Lines,5 DIP Lines, 1 X-ray,13 AOI,2 Sample test machines.
PCB&PCBA Capacity:
| 1 | Material | FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material,PI Material,BT Material,PPO,PPE etc. |
| 2 | Board thickness | Mass production:394mil(10mm) Samples:17.5mm |
| 3 | Surface finish | HASL,Immersion Gold,Immersion Tin,OSP,ENIG+OSP,Immersion Silver,ENEPIG,Gold Finger |
| 4 | PCB Max panel size | 1150mm × 560mm |
| 5 | Layer | Mass production:2~58 layers/Pilot run: 64 layers,Flexible PCB: 1-12 Layers |
| 6 | Min hole size | Mechanical drill:0.15mm Laser drill:3mil(0.075mm) |
| 7 | PCBA QC | X-ray,AOI Test,Functional Test,QC,QA,QE |
| 8 | Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Back drilling, Resistance control,Impedance Requirement. |
| 9 | Our service | PCB,Turnkey PCBA,Housing, PCB Assembly,Component sourcing,PCB manufacturing |
| 10 | SMT Capacity | 700Million Points/Day,BGA,01005 |
| 11 | DIP Capacity | 0.5Million Points/Day |
| 12 | Certificate | RoHS/ISO9001/TS16949/UL/ISO14001/ISO13485 |
