TG FR4 Multilayer PCB Board
TG FR4 Prototype Multilayer PCB Board
Multilayer PCB Board Prototype Printed Circuit Board Multilayer PCB Circuit Board
1. We offer One-shop PCAB/PCB manufacturing service
2. 20 years of turnkey OEM experience
3. We can provide F4B,F4BK, Tectonic,Arlon,Rogers material PCB
4. Timely customizations of PCBs and PCBAs
2. Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technolog
2) Various sizes components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity
PCBA Capability
|
Article |
Description |
Capability |
|
|
Sercive |
PCB and SMT assembly with one-stop service |
||
|
Material |
Laminate materials |
FR4, high TG FR4, high frequency, alum, FPC |
|
|
Board cutting |
Number of layers |
1-48 |
|
|
Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) |
||
|
Board thickness |
Standard |
(0.1-4mm±10%) |
|
|
Min. |
Single/Double:0.008±0.004” |
||
|
4layer:0.01±0.008” |
|||
|
8layer:0.01±0.008” |
|||
|
Bow and twist |
7/1000 |
||
|
Copper weight |
Outer Cu weight |
0.5-4 0z |
|
|
Inner Cu weight |
0.5-3 0z |
||
|
Drilling |
Min size |
0.0078”(0.2mm) |
|
|
Drill deviation |
±0.002″(0.05mm) |
||
|
PTH hole tolerance |
±0.002″(0.005mm) |
||
|
NPTH hole tolerance |
±0.002″(0.005mm) |
||
|
Solder mask
|
Color |
Green,white,black,red,blue… |
|
|
Min solder mask clearanace |
0.003″(0.07mm) |
||
|
Thickness |
(0.012*0.017mm) |
||
|
Silkscreen |
Color |
white,black,yellow,blue… |
|
|
Min size |
0.006″(0.15mm) |
||
|
E-test |
Function Test |
100% Functional test |
|
|
PCBA Testing |
X-ray,AOI Test,Functional test |
||
|
Pcb assembly |
one-stop service electronic manufacxturer service |
||
|
Component sourcing |
Yes |
||
|
Certificate |
IATF16949,ISO9001 |
||
|
Delivery time: |
PCB |
3-12days |
|
|
PCBA |
8-20days |
||
|
Tolerance of pcb |
±5% |
||
|
Max size of finish board |
450*450mm |
||
|
MOQ |
NO MOQ (1pcs) |
||
|
Surface Finish |
HASL,ENIG,immersion silver,immersion tin,OSP… |
||
|
PCB outline |
Square,circle,irregular(with jigs) |
||
|
package |
QFN,BGA,SSOP,PLCC,LGA |
||
|
Sub-assembly |
Plastic,metal,screen |
||
Capable
Leadsintec offers one-stop services from PCB designing, manufacturing, assembling, components soucing, programming to testing.
Confidential and Nondisclosure Agreement
We protect the Intellectual Property for our customers in the whole process. Our staff of trained professionals is all working under a strict confidentiality contract and keep[ the business secrets.
Flexibility
Customers-oriented. We forever center on customers’ demands, constantly update and introduce technology, fully understand customers’ requirements and offer our professional suggestion.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
