OEM BOM Custom PCB Assembly
OEM Gerber File BOM Custom PCB Assembly
OEM gerber file BOM customized electronic circuit board pcb pcba assembly
PRODUCT DETAILS
|
Name |
Electronic Customized One Stop Lead Free Electronic OEM DIP Smt PCBA Board |
Keyword |
Low Volume Pcb Assembly |
|---|---|---|---|
|
Layers Count |
1-48 |
Materials |
FR4, Aluminum Base, CEM-3, Rogers And More |
|
Minimum Hole Size |
0.15mm |
Surface Finishing |
Lead-free HASL, ENIG, Immersion Silver, Gold Plating, Immersion Tin And Gold Finger |
|
Min. Hole Size |
0.1mm,0.2 Mm |
Silkscreen Color |
White,black |
|
ROHS |
CANEC1308721101 |
Process Characteristics |
HDI Blind Buried Hole Process, High BGA Density, Small Hole-To-Line Spacing |
|
Solder Mask |
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue |
||
|
High Light |
dip pcba , Smt oem pcba , High Volume PCB Assembly Smt |
||
PRODUCT DESCRIPTION
Shenzhen Custom Printed Circuit Board Manufacturer, Electronic PCB DIP / SMT PCBA Assembly
PCBA options:
Prototype PCB Assembly
Low-Volume, High Mix PCB Assembly
High Volume PCB Assembly
Consigned & Partial PCB Assembly
Full Turnkey PCB Assembly
Our production capacity:
|
PCB Item |
Manufacture Capacity |
|
Layer Counts |
1--48L |
|
Base Material |
FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B) |
|
Material Thickness(mm) |
0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 |
|
Max board size(mm) |
1200x400mm |
|
Board Outline Tolerance |
±0.15mm |
|
Board Thickness |
0.4mm--3.2mm |
|
Thickness Tolerance |
±8% |
|
Minimum line/space |
0.1mm |
|
Min Annular Ring |
0.1mm |
|
SMD Pitch |
0.3mm |
|
Holes |
|
|
Min Hole Size(mechanical) |
0.2mm |
|
Min Hole Size(laser hole) |
0.1mm |
|
Hole Size Tol (+/-) |
PTH:±0.075mm;NPTH: ±0.05mm |
|
Hole Position Tol |
±0.075mm |
|
Plating |
|
|
HASL/LF HAL |
2.5um |
|
Immersion Gold |
Nickel 3-7um Au:1-5u'' |
|
Surface Finish |
HAL,ENIG,Plated Gold,Immersion Gold,OSP |
|
Copper |
|
|
Copper Weight |
0.5--6oz |
|
Color |
|
|
Solder mask |
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue |
|
Silk screen |
White, Black, Blue,Yellow |
|
Acceptable File Format |
Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 |
|
Certificate |
IATF16949, ISO13485, ISO9001 |
Leadsintec is high-end pcba factory, mainly service for customers involved in automotive electronic pcba, medical device, , smart home pcba, industrial pcba, communication pcba, military & aviation pcba.
