High Frequency Electrical EMS PCB Assembly OSP High TG FR4 OEM
High Frequency Electrical EMS PCB Assembly OSP High TG FR4 OEM
ems services electrical pcb circuit board assembly manufacturer
PCB or PCB Assembly files requests
1) Gerber files of the PCB Board
2) BOM(Bill of material) for assembly
To short the lead time,please kindly advertise us if there is any acceptable components substitution.
3) Testing method & Test fixtures if necessary.
4) programming files & programming tool if necessary
5) Schematic if necessary
Product Description:
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) | ||
| Board thickness | Standard | (0.1-4mm±10%) | |
| Min. | Single/Double:0.008±0.004” | ||
| 4layer:0.01±0.008” | |||
| 8layer:0.01±0.008” | |||
| Bow and twist | 7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”(0.2mm) | |
| Drill deviation | ±0.002″(0.05mm) | ||
| PTH hole tolerance | ±0.002″(0.005mm) | ||
| NPTH hole tolerance | ±0.002″(0.005mm) | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″(0.07mm) | ||
| Thickness | (0.012*0.017mm) | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″(0.15mm) | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949, ISO13485, ISO9001 | ||
| Delivery time: | PCB | 3-12days | |
| PCBA | 8-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 450*450mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
Leadsintec is the sole middle scale pcba assembly factory, with ISO & IATF certificates at the same time, can ensure high quality pcba service for customers of aerospace, automotive, medical, industry, communication, smart home, military etc.
Leadsintec focus on muti-varieties and small batch quick turn pcb prototype over 20 years, with no MOQ, no need to open stencil, fastest pcb delivery in 4hs.
Leadsintec insist on taking high quality pcb assembly route, we can flexiblely service for small batch pcb prototype, middle batch pcb manufacturing, mass pcb assembly for customers of military, smart home, power communication, industrial control, medical, automotive and aerospace with ISO14000, ISO13485, ISO9001 and IATF16949 certificates.
With advanced pcb printing & assembly devices, complete quality management, ERP online control, professional engineer team, we are confident to provide best quality and precise pcb assembly solutions.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
