One Stop Turnkey PCB Electronic Components 4mil FR4 Halogen Free CEM3
One Stop Turnkey PCB Electronic Components 4mil FR4 Halogen Free
Onestop Turnkey Pcb Pcba Main Circuit Ems Pcb Assembly
Our professional electrical engineers are always ready to conduct a quick yet careful check on your Gerber files and BOM so that your assembly manufacturing can be smoothly implemented with no defects or issues. We will help you balance between cost and performance.
1. Detailed Specification of PCB Board Manufacturing
| 1 | Layer | 1-48 layer |
| 2 | Material | FR-4,CEM-1,CEM3,Hight TG,FR4 Halogen Free,FR-1,FR-2,Aluminum |
| 3 | Board thickness | 0.4mm-4mm |
| 4 | Max.finished board side | 700mm*460mm |
| 5 | Min.drilled hole size | 0.25mm |
| 6 | Min.line width | 0.10mm(4mil) |
| 7 | Min.line spaceing | 0.10mm(4mil) |
| 8 | Surface finish/treatment | HASL/HASL lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating |
| 9 | Copper thickness | 1/2OZ 1OZ 2OZ 3OZ |
| 10 | Solder mask color | green/black/white/red/blue/yellow |
| 11 | Inner packing | Vacuum packing,Plastic bag |
| 12 | Outer packing | Standard carton packing |
| 13 | Hole tolerance | PTH:±0.076,NTPH:±0.05 |
| 14 | Certificate | IATF16949, ISO13485, ISO9001 |
| 15 | Profiling Punching | Routing,V-CUT,Beveling |
| 16 | Assembly Service | Providing OEM service to all sorts of printed circuit board assembly |
2. Detailed Terms for PCB Assembly
| Technical Requirement | Professional Surface-mounting and Through-hole soldering Technology |
| Various sizes like 1206,0805,0603 components SMT technology | |
| ICT(In Circuit Test),FCT(Functional Circuit Test) technology | |
| PCB Assembly With UL,CE,FCC,Rohs Approval | |
| Nitrogen gas reflow soldering technology for SMT | |
| High Standard SMT&Solder Assembly Line | |
| High density interconnected board placement technology capacity | |
| Quote&Production Requirement | Gerber File or PCB File for Bare PCB Board Fabrication |
| Bom(Bill of Material) for Assembly,PNP(Pick and Place file) and Components Position also needed in assembly | |
| To reduce the quote time, please provide us the full part number for each components,Quantity per board also the quantity for orders. | |
| Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate | |
| OEM/SMT/EMS Services | PCBA, PCB assembly: SMT & PTH & BGA |
| PCBA and enclosure design | |
| Components sourcing and purchasing | |
| Quick prototyping | |
| Plastic injection molding | |
| Metal sheet stamping | |
| Final assembly | |
| Test: AOI, In-Circuit Test (ICT), Functional Test (FCT) | |
| Custom clearance for material importing and product exporting | |
| Other PCB Assembly Equipments | SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4 |
| Reflow Oven: FolunGwin FL-RX860 | |
| Wave Soldering Machine: FolunGwin ADS300 | |
| Automated Optical Inspection (AOI): Aleader ALD-H-350B,X-RAY Testing Service | |
| Fully Automatic SMT Stencil Printer: FolunGwin Win-5 |
Technical Requirement for pcb assembly:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
Production Requirement for pcb assembly:
1. Gerber Files (Eagle and PCB File are available).
2. BOM list.
3. Clear pictures of PCBA or PCBA samples to us.
4. Pick N Place file.
5. Test procedure for PCBA.
Leadsintec is the independent export pcba assembly factory over 20 years, who are recognized as the top 10 pcba manufactuerer global, serving for customers of smart home pcba,automotive circuit board, medical pcba, industrial pcba, communication pcba, safety protection pcba, aviation pcba and military pcba etc.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
