Custom Electrical PCB Cable Assembly OSP 3OZ PCB Wire Harness
Custom Electrical PCB Cable Assembly OSP 3OZ PCB Wire Harness
PCB Cable Assembly Custom Electrical PCB Wire Harness Connector Cable Assembly
Product Description:
|
Article
|
Description
|
Description
|
|
Sercive
|
PCB and SMT assembly with one-stop service
|
|
|
Material
|
Laminate materials
|
FR4, high TG FR4, high frequency, alum, FPC
|
|
Board cutting |
Number of layers
|
1-48
|
|
Min.thickness for inner layers (Cu thickness are excluded)
|
0.003”(0.07mm)
|
|
|
Board thickness |
Standard
|
Standard
|
|
Min |
Single/Double:0.008±0.004”
|
|
|
4layer:0.01±0.008”
|
||
|
8layer:0.01±0.008”
|
||
|
Bow and twist
|
no more than 7/1000
|
|
|
Copper weight
|
Outer Cu weight
|
0.5-4 0z
|
|
|
Inner Cu weight
|
0.5-3 0z
|
|
Drilling |
Min size
|
0.0078”(0.2mm)
|
|
Drill deviation
|
±0.002″(0.05mm)
|
|
|
PTH hole tolerance
|
±0.002″(0.005mm)
|
|
|
NPTH hole tolerance
|
±0.002″(0.005mm)
|
|
|
Solder mask |
Color
|
Green,white,black,red,blue…
|
|
Min solder mask clearanace
|
0.003″(0.07mm)
|
|
|
Thickness
|
(0.012*0.017mm)
|
|
|
Silkscreen |
Color
|
white,black,yellow,blue…
|
|
Min size
|
0.006″(0.15mm)
|
|
|
E-test
|
Function Test
|
100% Functional test
|
|
PCBA Testing
|
X-ray,AOI Test,Functional test
|
|
|
Pcb assembly
|
one-stop service electronic manufacxturer service
|
|
|
Component sourcing
|
Yes
|
|
|
Certificate
|
IATF16949, ISO13485, ISO9001
|
|
|
Delivery time:
|
PCB
|
3-8 days
|
|
PCBA
|
10-20 days
|
|
|
Tolerance of pcb
|
±5%
|
|
|
MOQ
|
No MOQ ( 1 PCS )
|
|
|
Surface Finish
|
HASL,ENIG,immersion silver,immersion tin,OSP…
|
|
|
PCB outline
|
Square,circle,irregular(with jigs)
|
|
|
package
|
QFN,BGA,SSOP,PLCC,LGA
|
|
|
Sub-assembly
|
Plastic,metal,screen
|
|
1) Our Services & Strength:
Leadsintec is the best pcb manufacturing and pcb assembly factory globally, with ISO9001, ISO13485, 14000, and IATF16949 certificates simultaneously.
Leadsintec keeps pace with the times, has imported advanced YAMAHA, MADATA, selective wave soldering, 3D AOI, X-RAY etc equiments, we can provide original package componets agent service, custom pcb manufacturing, precise pcb assembly, accurate pcb printing, save your cost and time at the same time.
All PCBA are double Check by Machines and QC work , Welcome to Visit our factory!
2) Company Introduction:
Leadsintec provide full turnkey contract included Custom design, PCB prototype, PCB, PCBA, PCB Assembly, testing, accessories and cables, plastic enclosure,and packaging.box building.
EMS include consumers electronic ,medicla, industrial,power control, automotive. Temperature & Humidity ,Internet & Communication Smart Home Security etc device .
3) More PCBA Case:
Our services specialize in prototyping & OEM and small-volume production, making your requirment complete on the one-stop destination of boards fabrication and assembly.
Leadsintec regards high quality pcb fabrication and assembly as the life of our pcba factory, we pay much more attention to automotice pcba, medical pcba, industrial pcba, communication pcba, smart home pcba, military pcba and aviatio pcba etc.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
