Ip20 Poe Injector Gigabit Interface Converter For Ip Security Cameras
Product Description:
This IP20 PoE injector is designed for industrial applications and is certified to meet the strictest safety approvals, including CUL/UL, CE, CB, FCC, and KCC. It is capable of delivering up to 1000 Mbps data rates over a single-mode or multi-mode fiber connection, with a frequency of 47 to 63Hz (50/60Hz typ.). The operating humidity range is 20% to 80% without condensation, ensuring reliable performance in the most demanding industrial environments.
Featuring a robust design, the IP20 PoE injector is ideal for applications requiring high-speed fiber connectivity with PoE power supply. It simplifies deployment of devices such as IP cameras, VoIP phones, and wireless access points, eliminating the need for extra power cables. The industrial fiber PoE injector is easy to install and configure, making it an ideal solution for industrial applications.
Features:
- Product Name: IP20 PoE injector
- Data Rate: 1000Mbps
- Frequency: 47 To 63Hz (50/60Hz Typ.)
- Storage Humidity: 10% To 90%, Non-condensation
- Mounting: Wall-mounted
- Fiber Type: Single-mode/Multi-mode
Applications:
The PROCET PT-PSE109GBRO-A-S IP20 PoE injector is an industrial grade, 802.3bt compliant device designed to provide Power-over-Ethernet (PoE) connections for both data and power. It is an ideal solution for Ethernet applications that require data rates up to 1000Mbps and PoE power up to 95W. With a 55Vdc output voltage and an operating humidity of 20% to 80%, non-condensation, it is designed for use in a wide range of harsh industrial environments. This product is manufactured by PROCET, a leading supplier of PoE and fiber-optic solutions, based in Dongguan, China. The PT-PSE109GBRO-A-S Fiber PoE Injector is a reliable, cost-effective solution for powering and providing data connectivity for wireless access points, IP cameras, and other PoE-powered devices over fiber.
Customization:
- Brand Name: PROCET
- Model Number: 109GBRO-A-S
- Place of Origin: Dongguan China
- Color: Black
- Operating Temperature: -40℃ To 65℃
- Frequency: 47 To 63Hz (50/60Hz Typ.)
- Operating Humidity: 20% To 80%, Non-condensation
- AC Input Current: 2.0A
- 95W 802.3bt fiber PoE injector
- Gigabit fiber PoE Injector
- High efficiency, low power consumption
- Wide operating temperature range
- Robust mechanical design
| Warranty | 2 years |
| Safety Approvals | cUL/UL, CE, CB, FCC, KCC |
| Key Features | Industrial Fiber PoE can be outdoor use by covered with waterproof case |
| Surge protection both at PoE port and AC port | |
| 1000Base-FX to 1000Base-TX | |
| SFP slot for Multi mode or Single mode SFP transceiver | |
| Gigabit data rates | |
| AC power cord with optional US or EU plug or other standard plug | |
| IP20 high-impact metal enclosure | |
| Extend temperature from -40℃ to 65℃ | |
| Diagnostic LEDs | |
| Part Number | PT-PSE109GBRO-A-S IP20 PoE injector |
| Ports condition | SFP Port*1, LAN Port*1, AC Input Port*1, PoE Output Port*1 |
| Regulatory Compliance | IEEE802.3bt |
| RoHS Compliance | |
| WEEE Compliance | |
| Pass Through Data Rates | 1000 Mbps |
| Output | Pin Assignment and Polarity: |
| 4/5(+), 7/8(-) and 3/6(+),1/2(-) | |
| Output Power Voltage: 55Vdc | |
| User Port Power: 95W Guaranteen |
Support and Services:
IP20 PoE injector offers 24/7 technical support and service. Our team of experienced technicians is available to help you troubleshoot any issues you may have with your Fiber PoE Injector. We provide a comprehensive range of support options, including:
- Phone and email support
- Online technical support
- Live chat support
- On-site technical support
- Software and firmware updates
- Hardware repair and replacement
If you have any questions or need any help, please don't hesitate to contact us. We are here to help you get the most out of your Fiber PoE Injector.
Packing and Shipping:
The Fiber PoE Injector is packaged in a cardboard box containing the product, user manual, and warranty information.
The box is then shipped in a bubble-wrapped box with tape for extra protection during shipment.
The box is labeled with the product name, serial number, and shipping destination.
FAQ:
Brand Name: PROCET
Model Number: 109GBRO-A-S
Place of Origin: Dongguan China
FAQ
Q1: What is IP20 PoE injector?
A1: Fiber PoE Injector is a product made by PROCET, model number is 109GBRO-A-S IP20 PoE injector. It is an Ethernet over fiber converter with PoE injector function. It is made in Dongguan China.
Q2: What kind of fiber connector does IP20 PoE injector support?
A2: Fiber PoE Injector supports SC fiber connectors.
Q3: What is the transmission distance of Fiber PoE Injector?
A3: The transmission distance of Fiber PoE Injector is up to 10km.
Q4: What is the power output of Fiber PoE Injector?
A4: The power output of Fiber PoE Injector is up to 30W.
Q5: What is the working temperature of Fiber PoE Injector?
A5: The working temperature of Fiber PoE Injector is from -40℃ to 75℃.
