Industrial Din Rail 95 Watt PoE Injector Output 50Vdc To 57Vdc
Procet Industrial Din-rail Fiber 95W PoE injector Output 50-57Vdc
Key Specifications/Special Features:
1. PT-PSE105GW-D is a single port midspan Injector with 4 Pair PoE up to 95 watts of power with 6Kv surge protection.
2. - Industrial Fiber PoE can be outdoor use by covered with waterproof case
- Surge protection at PoE port
- 1000Base-FX to 10/100/1000Base-TX
- SFP slot for Multi mode or Single mode SFP transceiver
- Gigabit data rates
- DIN Rail mount
- IP40 high-impact metal enclosure
- Extend temperature from -40℃ to 65℃
- Diagnostic LEDs
3. Mechanical Characteristics
- Case: Metal
- Color: Black
- Mounting: DIN-rail
- IP Rated: IP40
- Connectors: Shielded RJ-45*1, SFP slot*1
- Size:144.5 X 96 X 35.4mm
- Weight: 485g(1.1lb)
| Parameter | Description |
| Key Features | IP40 high-impact metal enclosure |
| Ports condition | LAN Port*1, AC Input Port*1, PoE Output Port*1, SFP Port*1 |
| Regulatory Compliance | IEEE802.3bt RoHS Compliance WEEE Compliance |
| Pass Through Data Rates | 10/100/1000 Mbps |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 Common mode surge protection(10/700us): 6KV Differential mode surge protection (10/700us): 1.5KV |
| AC Surge Protection | Line-Earth 1.2/50us (8/20us): 2KV Line-Line 1.2/50us (8/20us): 1KV |
| Mechanical Characteristics | |
| Warranty5 | 5 year |
| Safety Approvals | cUL/UL, CE, CB, FCC |
