75w Dc Poe Injector Industrial Grade Lightning Proof Poe Power Supply Device
PROCET PoE Injector Industrial Grade Lightning-proof PoE Power Supply Device, Voltage Output Of 55Vdc, Up To 75W Max Power, Wide Temperature -40℃ to 65℃, PT-PSE107GHRO-A With 6Kv Surge Protection
Industrial PoE can be outdoor use by covered with a waterproof case
Extend temperature from -40℃ to 65℃
Lighting Protection both at AC and PoE port
Gigabit data rates
IP20 high-impact metal enclosure
AC power cord with optional US or EU plug or other standard plugs
Diagnostic LEDs
| Parameter | Description |
| Part Number | PT-PSE107GHRO-A |
| Ports condition | LAN Port*1, AC Input Port*1, PoE Output Port*1 |
| Regulatory Compliance | IEEE802.3bt |
| RoHS Compliance | |
| WEEE Compliance | |
| Pass Through Data Rates | 10/100/1000 Mbps |
| Output | Pin Assignment and Polarity: |
| 4/5(+), 7/8(-) and 3/6(+),1/2(-) | |
| Output Power Voltage: 55Vdc | |
| User Port Power: 75W Guaranteen | |
| Input | AC Input Voltage:90 to 264Vac(100 to 240Vac Rated) |
| AC Input Current: 1.5A | |
| Frequency: 47 to 63Hz (50/60Hz Typ.) | |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 |
| Common mode surge protection(10/700us): 6KV | |
| Differential mode surge protection (10/700us): 1.5KV | |
| AC Surge Protection | Line-Earth 1.2/50us (8/20us): 6KV |
| Line-Line 1.2/50us (8/20us): 4KV | |
| LED Indicator | Power Indicator: Green |
| PoE Load Indicator: Green | |
| Safety Approvals | CE, FCC |
