Industrial Dc To Dc 10gb Poe Injector 60w Fiber Adapter 802.3bt
PT-PSE105GWS-E-10 is a single-port, industrial-scale, fiber optic boost PoE media converter with PoE function. It provides 55Vdc, 1.1A power for remote PDs over full 4 pairs output with 6KV (10/700us) surge protection. 1 SFP+ uplink at 10G Fiber high speed enables distance extension over fiber optic cabling to power over ethernet Powered Devices (PDs), 10GBASE-X SFP+ to 10G Base-T.
It works for 60W power over ethernet PDs, such as wireless access points, network cameras, Microwave radios, and other high-power Ethernet terminals. It is fully compliant with IEEE802.3bt and also backward compatible to 802.3af/at standard.
Designed for indoor use but can work outdoor by being covered with a waterproof case. It works with an input voltage of 12-55Vdc and operates from -40℃ to 65℃. It has a detecting chip inside, which will detect and classify PD before powering it. It will not apply power until a standard-compliant PD is detected. The effective distance is 100 meters over Cat5e/Cat6 cables. This model is equipped standard DIN rail mounting bracket, which can easily jam into the guide rail.
| Parameter | Description |
| Key Features | Industrial SFP+ Fiber PoE can be outdoor use by covered with waterproof case |
| Surge protection at PoE port | |
| 10GBASE-X SFP+ to 10G Base-T | |
| SFP+ slot for Multi mode or Single mode SFP+ transceiver | |
| 10G/5G/2.5G/1G BASE-T auto-negotiation RJ45 Interfaces | |
| 12-55VDC input make it possible for solar application | |
| DIN Rail mount | |
| IP40 high-impact metal enclosure | |
| Extend temperature from -40℃ to 65℃ | |
| Diagnostic LEDs | |
| Output | Pin Assignment and Polarity: |
| 4/5(+), 7/8(-) & 3/6(+),1/2(-) | |
| Output Power Voltage: 55Vdc | |
| User Port Power: 60W Guaranteen | |
| Input | DC Input Voltage: 12 to 55 Vdc |
| DC Input Current: 10.0A | |
| PoE Surge Protection | Protected line: 1,2,3,4,5,6,7,8 |
| Common mode surge protection(10/700us): 6KV | |
| Differential mode surge protection (10/700us): 1.5KV | |
| Mechanical Characteristics | Case: Metal |
| Color: Black | |
| Mounting: DIN-rail | |
| IP Rated: IP40 | |
| Connectors: Shielded RJ-45*1, SFP slot*1 | |
| Size: 144.5mmX 104.2mmX 60mm | |
| Weight: 819g(1.8lb) |
Specification
Standard
- IEEE802.3u 100Base-Tx Fast Ethernet
- IEEE802.3ab 1000Base-T Gigabit Ethernet
- IEEE 802.3bz 2.5G/5GBase-T
- IEEE 802.3an 10GBase_t
- IEEE 802.3ae 10Gbps Ethernet
- Full compliant with IEEE802.3af/at/bt
- RoHS Compliance
- WEEE Compliance
Input & Output
- Input :12-55Vdc 10.0A
- Output: 55Vdc 1100mA
- Power Pins: 4/5(+), 7/8(-) & 3/6(+),1/2(-)
- Data Speed: 10GBASE-X SFP+ slot
- 10G/5G/2.5G/1G BASE-T auto-negotiation RJ45 Interfaces
Surge Protection
- Protected line: 1,2,3,4,5,6,7,8
- Common mode surge protection(10/700us): 6KV
- Differential mode surge protection (10/700us): 1.5KV
Mechanical Characteristics
- Case: Metal
- Color: Black
- Mounting: DIN-rail
- IP Rated: IP40
- Size: 144.5mm X 104.2mm X 60mm
- Weight: 819g
