Cubic Boron Nitride Grade CBN A80 Widely Used For Grinding Wheel

Dark Brown CBN A80 Cubic Boron Nitride 40-400 mesh

Description:

Cubic Boron Nitride powder, used in precision grinding, grinding, polishing and ultra-finishing to achieve high-precision machined surface.
Applicable to resin, metal, ceramic and other binding agent system, can also be used for the production of poly-crystalline composite sheet sintered body, it can use as loose abrasive particles, abrasive paste. The black cubic boron nitride CBN has excellent chemical and physical properties, such as the high hardness after diamond, thermal stability and chemical inertness, as superhard abrasive in different industries to obtain a wide range of applications, is now becoming the automotive, aerospace, mechanical electronics, microelectronics and other industries indispensable important materials, therefore, the industrial developed countries have received great attention. There are many methods for synthesizing CBN in addition to static high pressure catalyst, such as static high pressure direct conversion method, dynamic impact method, vapor deposition method, and some methods such as vapor deposition method develop rapidly. But so far the main method of industrial synthetic CBN is static high pressure catalyst method, the synthesis of CBN is mainly focused on this aspect.

Improve grinding efficiency to a new level
CBN/cubic boron nitride powder is with high hardness and high temperature resistance, four times that of traditional abrasive in wear resistance, and have extraordinary thermal conductivity.
There are hundreds of raw materials needed to use CBN to grind in present manufacturing market, from aerospace superalloys and thermal spraying to the hardened steel in automotive bearing and gear industry to improve efficiency and get the shortest processing time.

cBN Series Mesh Size Available:

cBN Series Micron Size Available:

Abrasive Materials Mesh Size Comparison List

cBN Mesh & Micron Series

- cBN B10

Black, single crystal, irregular crystal, low strength but strong self-sharpening, easy to break. It is widely used in resin bond system and low temperature grinding.

- cBN B20

Black, single crystal, medium blocky, high strength and thermal stability. It has a wide range of applications taking into consideration of the grinding efficiency and the life of grinding wheel, and it is widely used in ceramic and metal bond systems.

- cBN B30

Black, medium strength, irregular shape, and prominent sharp angles to ensure high grinding efficiency. It is mainly used in resin bond and ceramic bond systems.

- cBN A40

Golden yellow, complete crystal shape, high strength and extremely high thermal stability, it's suitable for electroplating tools and metal bond systems.

- cBN A50

Brown-black, irregular shape, prominent acute angle, high strength, high thermal stability, it's suitable for heavy grinding of ceramic bond, metal bond and resin bond.

- cBN A60

Dark brown, complete crystal shape, high strength, high thermal stability, and it is widely used in metal bond systems and electroplating tools.

- cBN A70

Golden single crystal block particle with high toughness and thermal stability. It is mainly used for electroplating or metal bond, suitable for grinding hard tool steel, carbon alloy and super cobalt alloy and other difficult-to-machine materials.

- cBN A80

Dark brown, non-blocky regular crystal form with very prominent acute angles. It provides high service life and high thermal stability while ensuring grinding efficiency. It is suitable for ceramic bond, metal bond and resin bond.

- CBN A80M Micron Size

A80M is a higher-grade product among domestic CBN products. It has the characteristics of high strength, high toughness and high thermal stability. It is the best choice for the ceramic bond CBN grinding wheel for processing automobile camshafts and crankshafts. It has a strong grinding force while the stability is much higher than other products. The surface cleanliness is specially treated, which is especially suitable for the production of PCBN and CBN sintered bodies.

Features and Advantages of Harmony CBN Powder
- It has high hardness, high wear resistance and good thermal stability. Suitable for processing hardened steel series parts.
- Good impact resistance, suitable for processing high hardness materials.
- High hardness, excellent wear resistance, high-speed continuous cutting.

Application of Harmony CBN Powder
- High-speed machining of precision car brake discs, brake discs and engine cylinder liners, gray iron, ductile iron, vermicular graphite cast iron and other parts.
- Intermittent, continuous, medium and high speed, semi-precision and precision turning, high-speed steel, gears, bearing rolls, carburizing and surfacing welding and other parts processing.
- Intermittent, low and medium speed, rough processing, high chromium, high nickel, alloy cast iron, chilled cast iron and high-speed continuous processing of gray cast iron, boron cast iron ball, graphite cast iron, heat-resistant alloy titanium alloy and other materials.
- Grinding and polishing of ferrous metals.
We can supply different types of CBN powder for sale, such as CBN micron powder, black and amber CBN with ISO certificates. Premium quality and performances are our two main advantages.
