GYTC8S Fiber Optic Overhead Cable Self Supporting Single Mode
| Product Name | GYXTC8S Fiber Optic Cable | Fiber Count | 4cores |
|---|---|---|---|
| Fiber Type | Singlemode | Overall Diameter | 7*13.6mm |
| Outer Jacket | HDPE | Steel Wire Strand Wire | 7x0.8mm |
| Length | 1-5km Per Wooden Drum | Cable Color | Black |
| High Light |
GYXTC8S Self Supporting Fiber Optic Cable,Aixton Self Supporting Fiber Optic Cable,Mini GYXTC8S Overhead Fiber Optic Cable |
||
mini GYTC8S Overhead Self Supporting Optical Cable Single mode GYXTC8S 4 6 8 12 core
Self-supported figure 8 optical cable with fibers placed in jelly filled loose buffer tube stranded around dielectric central member. The cable core is protected with jelly or waterblocking material to prevent water intrusion and migration. This set unit and galvanized steel messenger are covered with polyethylene outer jacket.
Specification:
Item Name:Fiber optical cable GYXTC8S.
Optical Mode:Singlemode/Multimode.
Fiber Diameters:G652, G655, 50/125μm, 62.5/125μm.
Total Fiber Count:2-12cores.
Bend Radius(Static/Dynamic):10D/20D.
Working Life:More than 25 years.
Application:Aerial self-supporting,Local network,Local network,Long distance network communication.
Construction
Coated outside diameter:125.0±0.1um Optical diber diameter:242±7um UV color fiber:standard chromatogram Blue,Orange,Green,Brown,Gray/Slate,White,Red,Black,Yellow,Violet,Rose/Pink,Aqua
|
Standards and Certificate:
Fiber optical cable complies with Standard YD/T 769-2003,IEC60794-1
Certificate:CE ROHS ISO9001
Characteristics
1. Good mechanical and temperature performance
2. High strength loose tube that is hydrolysis resistant
3. Special tube filling compound ensure a critical protection of fiber
4. Crush resistance and flexibility
| Fiber count | 6 core |
| Fiber Type: | G652D/G657A1/G657A2 |
| Crush Resistance Long term: | 300 (N/100MM) |
| Crush Resistance Short term: | 1000(N/100MM) |
| Overall Diameter | 9.5*18.3mm |
| Sheath | PE |
| Strand Steel wire | 7*0.8mm |
| Sample Status | In stock |
