600A Diesel Powered Welder Generators Turbocharged LCD Control
Price:
Negotiable
MOQ:
100 units mixed model
Delivery Time:
25 work days
Brand:
RAMS
Product Description
500A Diesel Welding Machine Generator Arc welding Brushless Self Excitation
MOQ:2units mixed model
• LCD control panel display, easy operation
• Anticorrosion, cold rolled steel canopy with acoustic foam, low noise, durability
• Over load protection, breaker protection
• Arc welding, welding line can extend to 30m
• Output current 600A,welding thickness 0.8-15mm
• Strong welding effect, no fear of thick plate and other factors, achieve instant arc, no bubbles,
no stick, beautiful welding forming
| Model No. | AXC1-600A | |
| alternator | Excitation mode | Brushless self excitation |
| The prime power | 30KW | |
| Rated frequency | 50Hz | |
| RPM | 1500r/min | |
| Rated voltage | 400V | |
| Insulation grade | H | |
| Safeguard grade | IP23 | |
| engine | engine | WP2.3D33E200 |
| Power/h | 30KW | |
| RPM | 1500r/min | |
| Startup | DC12V electric | |
| Engine type | Inline ,direct injection | |
| Intake mode | Turbo charged | |
| stroke | 4 | |
| Cylinder No. | 4 | |
| Bore x stroke | 100x115mm | |
| Governing control | Electron governor | |
| displacement | 2.289L | |
| fuel consumption | ≤200g/kWh | |
| Oil consumption | ≤1.5g/kWh | |
| genset | frequency | 50Hz |
| Rated voltage | 400V | |
| The prime power | 30KW | |
| The standby power | 32KW | |
| Rated ampere | Each phase 40.0A | |
| Max. ampere | Each phase 43.0A | |
| Phase No. | 3 phase | |
| noise | ≤75dB/7m | |
| size | 1800*900*1300 | |
| Net weight | 700KG | |
| Welding machine | Phase | 3 phase 380V 50Hz |
| Rated input ampere | 26A | |
| Rated input power | 17KVA | |
| rated welding A/V | 600A/36V | |
| Welding ampere | 600A60%DE | |
| 510A100%DE | ||
| no load voltage | 67±5V | |
| ampere set range | 20-600A | |
| Efficiency | ≥85% | |
| Power factor | >0.95 | |
| Insulation grade | F | |
| Cooling system | Air cooled | |
| Protection grade | IP21S | |
