Passive DCM Dispersion Compensation Module 1550nm 20-160KM Distance
Price:
Get latest price
MOQ:
1 Pcs
Delivery Time:
Negotiable
Brand:
SPACECOM or OEM
Product Description
1550nm Fiber Optic Passive DCM Dispersion Compensation
Product Description
| Name: | 1550nm Fiber Optic Passive DCM Dispersion Compensation Module | Model Number: | SPC-DCM-20 |
| Operation Temperature: | -5~+60℃ | Storage Temperature: | -40~+80℃ |
| Compensation Distance: | 20~160KM | Feature: | DCM |
|
Humidity:
|
10~85% | Warranty Time: | 1year |
Features
- G.652 optical fiber C-band 100% Slope compensation (Standard)
- Low insertion loss
- Low Polarization mode dispersion
- DWDM system broad-band dispersion compensation
- Performance compatible with Telcordia GR-2854-CORE
- Various Mechanical Structure, connectors are provided
- Recommend operation with SPACECOM mid-stage optical amplifier to get excellent character
Application
- Dispersion control
- SDH high speed optical transmission system
- DWDM optical transmission system
- CATV long haul optical transmission system.
- G.652fiber long haul system
