20 Tons Municipal Batch Pyrolysis Plant Industrial Scale
Pyrolysis Waste Municipal Machine 20 Tons Pyrolysis System Industrial Scale For Plants
The plastic waste that can be seen everywhere seriously pollutes our living environment, how to dispose of this plastic waste properly is increasingly important. Huayin waste plastic pyrolysis plant can recycle the waste plastic to fuel oil, carbon black, and gas through pyrolysis technology, the whole process is environmentally friendly and brings you a large profit.
Main features
| Our advantage | |
| Reactor material | Adopt Q245R/Q235R high pressure and temperature resistance steel plate to ensure longer service life. For some special raw materials, we use a special steel plate. |
| High efficiency discharging | Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution, and save labor and time. |
| Integrated condensing device | All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality |
| Auto feeding system | Auto feeder machine to feed raw material automatically, save labor and time. |
| Energy saving |
The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel. The combustible gas (that cannot be further cooled down into fuel oil )will be recycled into the furnace for heating the reactor, maximizing resource utilization. |
| Valves | All of the valves use stainless steel. |
| Non-pollution | Adopt 3 layers of ceramic packing dedusting device and water spray, finally, no black smoke discharged out. SGS emission report provided. |
| Safety devices | Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly. |
Output product and application
Fuel oil (50%-75%)
1. The main product - fuel oil produced by waste pyrolysis machine is widely used for industrial and commercial purposes. This fuel oil is a kind of good heating fuel that can be applied for boiler factories, cement factories, glass factories, steel mills, etc.
2. It also can be refined to diesel by the distillation machine. The distillation diesel can be used for diesel engines.
Carbon black (30%-35%)
1. It can be pressed into pellets for use in industrial heating.
2. It can be ground and refined into different standards.
Flammable Gas (8%-10%)
1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.
Specification
| Model | Reactor size | Capacity | Power | Landing area(m) |
| HY-10kg | HY1880*800 | 10kg/batch | 250W | 1*4 |
| HY-1T | HY1500*3000 | 1 T/batch | 13.5KW | 8*20 |
| HY-5T | HY2200*5500 | 5 T/batch | 29.4KW | 10*35 |
| HY-7T | HY2200*7500 | 7 T/batch | 29.4KW | 10*35 |
| HY-8T | HY2600*6600 | 8 T/batch | 29.4KW | 12*35 |
| HY-9T | HY2800*6000 | 9 T/batch | 29.4KW | 12*35 |
| HY-10T | HY2800*6600 | 10 T/batch | 32KW | 15*35 |
| HY-15T | HY2800*8000 | 15 T/batch | 34KW | 15*35 |
Our services
1. One-stop solution. We have more than 20 years of rich experience in manufacturing waste pyrolysis plants. We pay more attention to customer experience and customer satisfaction. As long as you need it, we are able to provide you with a better quality complete production line.
2. We have our own factory and trading company, no middlemen, more cost-effective, and it is more convenient for you to replace related parts, as long as there is a problem, we can provide a solution immediately, product quality is guaranteed.
3. We promise that our plants are efficient and have a long service life to ensure that you can quickly produce in batches.
4. Delivery time is 15-25 days.
5. We can send engineers on-site to guide installation and train your workers.
6. One-year warranty, lifelong maintenance of the equipment, providing professional use guidance services.
