CE ISO Waste Plastic To Fuel Machine 1 Tone Plastic Pyrolysis Plant
Profitable Business Plastic To Diesel Fuel Machine 1 Tone Plastic Pyrolysis Plant
Product description
Nowadays, with human exploitation and environmental degradation, natural energy especially oil energy is becoming less and less, on the contrary, municipal solid wastes are becoming more and more. Huayin waste plastic to diesel fuel pyrolysis machine can convert the normal daily wastes like plastic bags, and rubber scraps into fuel oil, which can be used as heating fuel in many industrial fields.
Output product and usage
Fuel Oil (50%-75%)
1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color and smell removal system, the final oil can be used in diesel engines like trucks, tractors, etc.
Carbon Black (30%-35%)
Slag for construction.
Flammable Gas (8%-10%)
1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.
Specification
| Item | Content | |
| Raw materials | Waste tyre/rubber | |
| Output | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas | |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch | |
| HY2200*5500 | 5 T/batch | |
| HY2200*7500 | 7 T/batch | |
| HY2600*6600 | 8 T/batch | |
| HY2800*6000 | 9 T/batch | |
| HY2800*6600 | 10 T/batch | |
| HY2800*8000 | 15 T/batch | |
| Remarks | Support customization | |
| Reactor material and thickness |
Q345R/Q245R/310S (Boiler plate/stainless steel) 16mm/18mm |
|
| Land area | 300-400㎡ (L30-40m*W10m) | |
| Number of workers | 3-4 | |
| Oil density and calorific value | 0.89g/cm³&44.30KJ/KG | |
| Processing time and power | 10-24 hours. Averagely 15KW/h | |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents | |
Main features
1. High efficiency. The feeding port of the pyrolysis reactor is 1400mm, so the waste material doesn’t need pretreatment, it can be put into the pyrolysis reactor directly with the auto feeder machine.
2. High stability. The rollers are engineered underfeeding port and oil outlet port which are external from the heating area to bring perfect rotating balance and longer service life.
3. Energy saving: Non-condensable gas will go back to the heating system for second burning as heating material, saving your heating fuel.
4. High oil yield: Larger condensation area to ensure sufficient condensation of oil gas into liquid oil.
5. Eco-friendly: The stainless steel deduster is filled with ceramic filters inside, which brings it strong dust adsorption capacity and a good dedusting effect.
6. High safety level: Equipped with Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.
Packing and shipping
All goods are packed with exported standards packages to make sure no damage during transportation.
Delivery time is 15 working days after receiving the deposit.
