Economic Type Small Pyrolysis Plant 1 Ton Plastic To Diesel Fuel Mobile
Economic Type Plastic To Diesel Fuel Plant 1 Ton Small Mobile Pyrolysis Plant For Oil
Product description
With the increasing awareness of environmental protection in the world, the harmless and resourceful disposal of waste tires/plastic has become an important trend. The waste plastic /tyre recycle to fuel oil machinery is designed to process the waste into valuable products -industrial fuel oil, carbon black, and steel wire through catalytic cracking technology. This green technology has created good economic and social benefits.
Output product and usage
| Output Products | Application |
| Fuel Oil (40%-55%) | 1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc. 2. Used in heavy oil generator for electricity generation. 3. Deep process it into diesel oil with our distillation plant, color, and smell removal system, the final oil can be used in trucks, tractors, etc. |
| Carbon Black (30%-35%) | 1. Make it to pellet or briquette as heating material. |
| Steel Wire (10%-15%) | Sell to iron and steel factory directly. |
| Flammable Gas (8%-10%) |
1. Recycled into the furnace to heat reactor instead of heating material. 2. Storage the excess gas to restart the next batch. |
Main features
| Our advantage | |
| Reactor material | Adopt Q245R/Q235R high pressure and temperature resistance steel plate to ensure longer service life. For some special raw materials, we use a special steel plate. |
| High efficiency discharging | Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution, and save labor and time. |
| Integrated condensing device | All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality |
| Auto feeding system | Auto feeder machine to feed raw material automatically, save labor and time. |
| Energy saving |
The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel. The combustible gas (that cannot be further cooled down into fuel oil )will be recycled into the furnace for heating the reactor, maximizing resource utilization. |
| Valves | All of the valves use stainless steel. |
| Non-pollution | Adopt 3 layers of ceramic packing dedusting device and water spray, finally, no black smoke discharged out. SGS emission report provided. |
| Safety devices | Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly. |
Specification
| Model | Reactor size | Capacity | Power | Landing area(m) |
| HY-10kg | HY1880*800 | 10kg/batch | 250W | 1*4 |
| HY-1T | HY1500*3000 | 1 T/batch | 13.5KW | 8*20 |
| HY-5T | HY2200*5500 | 5 T/batch | 29.4KW | 10*35 |
| HY-7T | HY2200*7500 | 7 T/batch | 29.4KW | 10*35 |
| HY-8T | HY2600*6600 | 8 T/batch | 29.4KW | 12*35 |
| HY-9T | HY2800*6000 | 9 T/batch | 29.4KW | 12*35 |
| HY-10T | HY2800*6600 | 10 T/batch | 32KW | 15*35 |
| HY-15T | HY2800*8000 | 15 T/batch | 34KW | 15*35 |
Our services
1. With over 20 years of manufacturing experience, we are confident to provide you with a quality pyrolysis plant at the most reasonable price.
2. Very short delivery time. The delivery time is usually 15 working days.
3. We can send engineers on-site to guide installation and train your workers, providing professional use guidance services.
4. One-year warranty, lifelong maintenance of the equipment, providing professional use guidance services.
