HC-SFS152 Mitsubishi AC Servo Drive Para Maquina De Coser For Robots

Price Negotiable

Price: $100-$1000

MOQ: 1/pc

Delivery Time: Negotiable

Brand: MITSUBISHI, MITSUBISHI

Product Description

Mitsubishi Mitsubishi AC Motor Servo Motor Para Maquina De Coser HC-SFS152

HC SFS Series

Features:

Medium inertia Three models, from low to high-speed, are available for various applications

Application examples:

● Material handling systems ● Robots ● X-Y tables

TechnIcal Parameter

Servo motor model	HC-SFS 52 (B)	HC-SFS 102 (B)	HC-SFS 152 (B)	HC-SFS 202 (B)	HC-SFS 352 (B)	HC-SFS 502 (B)	HC-SFS 702 (B)
Servo amplifier model	MR-J2S-60A/B	MR-J2S-100A/B	MR-J2S-200A/B	MR-J2S-200AB	MR-J2S-350A/B	MR-J2S-500A/B	MR-J2S-700A/B
Power facility capacity	1.0 [kVA]	1.7 [kVA]	2.5 [kVA]	3.5 [kVA]	5.5 [kVA]	7.5 [kVA]	10 [kVA]
Rated output	0.5 [KW]	1.0 [KW]	1.5 [KW]	2.0 [KW]	3.5 [KW]	5.0 [KW]	7.0 [KW]
Rated torque	2.39 [Nm]	4.78 [Nm]	7.16 [Nm]	9.55 [Nm]	16.7 [Nm]	23.9 [Nm]	33.4 [Nm]
Maximum torque	7.16 [Nm]	14.4 [Nm]	21.6 [Nm]	28.5 [Nm]	50.1 [Nm]	71.6 [Nm]	100 [Nm]
Rated rotation speed	2000[rpm]
Maximum rotation speed	3000[rpm]			2500[rpm]		2000[rpm]
Permissible instantaneous rotation speed	3450			2850		2300
Rated current [A]	3.2	6	9	11	17	28	35
Maximum current [A]	9.6	18	27	33	51	84	105
Weight	5[kg]	7[kg]	9[kg]	12[kg]	19[kg]	23[kg]	32[kg]
