0.1KW - 15kW Frequency Converter Inverter Mitsubishi FR-D720-1.5K
Price:
$99.00 - $699.00/Pieces
MOQ:
1/pc
Delivery Time:
Negotiable
Brand:
Mitsubishi
Product Description
Brand Original New FR-D720-1.5K Frequency Inverter Or Converter
FA-Inverter: Inverter
| Mitsubishi VFDs Inverter Three-phase | Mitsubishi VFDs Inverter FR-D720 0.1KW to 15kW | ||||||||||
| Model FR-D720-oK | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 15 |
| Model FR-D720-o-NA | 008 | 014 | 025 | 042 | 070 | 100 | 165 | 238 | 318 | — | — |
| Applicable motor capacity (kW)*1 | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 15 |
| Rated capacity (kVA)*2 | 0.3 | 0.6 | 1.0 | 1.7 | 2.8 | 4.0 | 6.6 | 9.5 | 12.7 | 17.9 | 23.1 |
| Rated current (A) | 0.8 | 1.4 | 2.5 | 4.2 | 7.0 | 10.0 | 16.5 | 23.8 | 31.8 | 45.0 | 58.0 |
| Overload current rating*3 | 150% 60s, 200% 0.5s (inverse-time characteristics) | ||||||||||
| Voltage*4 | Three-phase 200 to 240V | ||||||||||
| Regenerative braking torque*5 | 150% | 100% | 50% | 20% | |||||||
| Rated input AC voltage/frequency | Three-phase 200 to 240V 50Hz/60Hz | ||||||||||
| Permissible AC voltagefluctuation | 170 to 264V 50Hz/60Hz | ||||||||||
| Permissible frequency fluctuation | ±5% | ||||||||||
| Power supply capacity (kVA)*6 | 0.4 | 0.7 | 1.2 | 2.1 | 4.0 | 5.5 | 9.0 | 12.0 | 17.0 | 20.0 | 27.0 |
| Protective structure (JEM1030) | Enclosed type (IP20). | ||||||||||
| Cooling system | Self-cooling | Forced air cooling | |||||||||
| Approximate mass (kg) | 0.5 | 0.5 | 0.8 | 1.0 | 1.4 | 1.4 | 1.8 | 3.6 | 3.6 | 6.5 | 6.5 |
Product Feature:
Small-size inverter with a highest class standard of performance on a compact body.
[Features]
· This is the smallest in the Mitsubishi Electric inverter series.
· Can be installed side by side in contact with each other to save space.
· The inverter shall be used at an ambient temperature of 40°C or below.
· The cooling fan is designed to last long for up to 10 years.
· The design life is an estimated value, and is not guaranteed.
[Applications]
· Ideal for applications with transportation, packaging, textile, printing equipment, etc.
