200 - 240V Mitsubishi Electric Inverter FR-E820S-0030-4-60 FR-E820S-0.4K-1
For Mitsubishi New and Original Inverter FR-E820S-0030-4-60 0.4K or FR-E820S-0.4K-1
Inverter
|
SERIES |
FR-E800 SERIES |
|---|---|
|
TYPE |
FR-E800 RS485 INVERTER |
|
MINIMUM RATED VOLTAGE (V) |
200 |
|
MIN. PERMISSIBLE VOLTAGE (V) |
170 |
|
MAXIMUM RATED VOLTAGE (V) |
240 |
|
MAX. PERMISSIBLE VOLTAGE (V) |
264 |
|
CURRENT TYPE |
AC |
|
PHASES |
1 |
|
RATED OUTPUT CURRENT ND (A) |
3 |
|
RATED MOTOR CAPACITY ND (KW) |
0,4 |
|
CONTROL METHOD |
MAGNETIC FLUX VECTOR CONTROL |
|
MOTOR TYPE |
INDUCTION MOTOR, PM MOTOR |
|
BRAKE CHOPPER ED (%) |
30 |
|
INTEGRATED EMC FILTER |
NO |
|
SAFE TORQUE OFF (STO) |
YES |
|
REGENERATIVE (4Q) |
NO |
|
INTEGRATED DC CHOKE |
NO |
|
DISPLAY |
BUILT-IN |
|
DISPLAY TYPE |
4-DIGIT LED |
|
PLC FUNCTION |
YES |
|
PROGRAM MEMORY |
2K |
|
PROGRAM MEMORY UNIT |
STEPS |
|
INTEGRATED DIGITAL INPUTS |
7 |
|
DIGITAL OUTPUTS (TRANSISTOR) |
2 |
|
DIGITAL OUTPUTS (RELAY) |
1 |
|
INTEGRATED ANALOGUE INPUTS |
2 |
|
INTEGRATED ANALOGUE OUTPUTS |
1 |
|
IO TYPE OF TERMINAL BLOCK |
SPRING CLAMP |
|
EXPANDABLE |
YES |
|
RS-485 |
1 |
|
USB |
1 (MINI B) |
|
ETHERNET PORT |
NO |
|
BUILT-IN NETWORK |
MODBUS RTU |
|
LEAKAGE CURRENT (MA) |
1,2 |
|
POWER LOSS LD (W) |
- |
|
POWER LOSS ND (W) |
32 |
|
STANDBY POWER CONSUMPTION (W) |
- |
|
PROTECTION CLASS |
IP20 |
|
FREQUENCY RANGE (HZ) |
0,2–590 |
Product Dimensions & Weight
|
WIDTH (MM) |
68 |
|---|---|
|
HEIGHT (MM) |
128 |
|
DEPTH (MM) |
142,5 |
|
WEIGHT (KG) |
0,8 |
