30Watt 980nm Multi Function Detachable Diode Laser For Medical Cosmetology
Price:
Negotiable
MOQ:
1 Piece/Pieces
Delivery Time:
4-8weeks
Brand:
BWT
Product Description
Features:
980nm wavelength
30W output power
200μm fiber core diameter
0.22 NA
Additional Functions: Aiming beam Fiber & Power monitor Thermistor Exchangeable window(Optional)
Applications:
Medical use
Scientific research
|
Specifications(25℃)
|
Symbol
|
Unit
|
K980FAMCA-30.00W | |||
| Minimum | Typical | Maximum | ||||
| Optical Data | CW-Output Power | Po | W | 30 | - | - |
| Center Wavelength | λc | nm | 980±10 | |||
| Spectral Width (FWHM) | △λ | nm | 6 | |||
| Wavelength Shift with Temperature | △λ/△T | nm/℃ | - | 0.3 | - | |
| Wavelength Shift with Current | △λ/△A | A/℃ | - | 0.03 | - | |
| Electrical Data | Electrical-to-Optical Efficiency | PE | % | 50 | - | |
| Threshold current | lth | A | - | 0.7 | - | |
| Operating current | lop | A | - | - | 13 | |
| Operating voltage | Vop | V | - | 5.2 | 6 | |
| Slope Efficiency | η | W/A | - | 2.7 | - | |
|
Fiber Data
|
Core diameter | Dcore | μm | - | 200 | - |
| Numeric aperture | NA | NA | - | 0.22 | - | |
| Connector | - | - | - | SMA905 | - | |
| Thermistor | Rt | (K Ω)/(25℃) | 10±3% | |||
| PD | PD | µA | 200 2000 | |||
| Others | ESD | Vesd | V | - | - | 500 |
| Storage temperature | Tst | ℃ | -20 | - | 70 | |
| Lead Soldering Temp | Tls | ℃ | - | - | 260 | |
| Lead Soldering Time | t | sec | - | - | 10 | |
| Operating case temperature | Top | ℃ | 15 | - | 30 | |
| Relative Humidity | RH | % | 15 | - | 75 | |
| Aiming Beam | Output Power | Pa | mW | |||
| Wavelength | la | nm | 635±10 | |||
| Voltage | Va | V | 2.3 | |||
| Current | Ia | mA | 45 | 65 | ||
Instructions for use
- Avoid eye and skin exposure to direct radiation during operation.
- ESD precautions must be taken during storage, transportation and operation.
- Short-circuit is required between pins during storage and transportation.
- Use constant current power supply to avoid surge current during operation.
- Laser diode must be used according to the specifications.
- Laser diode must work with good cooling.
- Operation temperature ranges from 20℃ to 30℃ .
- Storage temperature ranges from -20℃ to +70℃.
- ESD precautions must be taken during storage, transportation and operation.
- Short-circuit is required between pins during storage and transportation.
- Please connect pins to wires by solder instead of using socket when operation current is higher than 6A.
- Soldering point should be close to the middle of the pins. Soldering temperature should be lower than 260℃ and time shorter than 10 second.
- Make sure the fiber output end is properly cleaned before operation of laser. Follow safety protocols to avoid injury when handling and cutting the fiber.- Use constant current power supply to avoid surge current during operation.
- Laser diode must be used according to the specifications.
- Laser diode must work with good cooling.
- Operation temperature ranges from 20℃ to 30℃ .
- Storage temperature ranges from -20℃ to +70℃.
