Saic Hongyan Mine Dump Wide Body Truck 371HP 6X4 CQ5763PTG384
Hongyan Mining 371HP 6X4 Wide Body Dump Truck (CQ5763PTG384)
Mining Truck, Demp Truck, Mine Dump Truck, Wide Body Truck
▎Strong bearing capacity and stability are suitable for various working conditions
Dump trucks need to face a variety of working conditions in engineering transportation operations, which may be driving on rugged road sections that are prone to rollover, or may be carrying heavy objects such as reinforced stone. These working conditions put forward higher requirements on the bearing capacity and stability of the dump truck. Based on the transportation needs of various working conditions, Hongyan King Kong dump truck has been scientifically designed in terms of bearing capacity and stability.
It uses a forged I-beam and has passed 700,000 fatigue tests, effectively enhancing the bearing capacity. In addition, its chassis is made of high-strength alloy material, and comes standard with a reinforced, wide front and narrow rear frame and rear stabilizer bar, which can effectively prevent the vehicle from rolling over and enhance the stability of the vehicle. Therefore, the Hongyan King Kong dump truck can be applied to a variety of working conditions, helping truckers ride the wind and waves on the engineering transportation road. Surging power, easy to deal with ramps and tunnels
When a dump truck drives on a ramp or a pit, it must have enough power to ensure the passability and the timeliness of transportation. In this regard, the perfect cooperation between the high-efficiency engine and the power system of the Hongyan King Kong dump truck makes drivers no longer worry about ramps and pits.
It is equipped with Cosso series engines, combined with FAST gearbox and FPT axle to form a powerful platinum power chain, which greatly improves the transmission efficiency of the transmission, reduces fuel consumption, and can continuously and efficiently output surging power. After testing, the maximum driving gradient of the Hongyan dump truck has reached 37%, which can be handled with ease even in the steep slope operation of the mountain tunnel.
| Basic Information | |||
| model: | CQ5763PTG384 | Drive form: | 6X4 |
| Vehicle weight: | 26 tons | Rated load: | 50 tons |
| Total mass: | 76 tons | Body size: | 8.53×3.3×4.18 meters |
| Maximum speed: | 52km/h | ||
| Engine parameters | |||
| engine model: | Sinotruk WD615.47 | Displacement: | 9.726L |
| Maximum output power: | 273kW | Maximum horsepower: | 371 hp |
| Maximum torque speed: | 1500/1100-1600N.r/min | Emission Standards: | Country II |
| Cargo box parameters | |||
| Cargo box size: | 5.6×3×1.6 meters | ||
| Bodywork parameters | |||
| Vehicle brand: | Hongyan Jieshi | Lifting form: | Hyward FC172--4700 |
| Maximum tipping angle: | 8 degrees | Other special instructions: | The rear tilt distance is 800mm, there is no rear tailgate, the bottom is 16mm and the side is 12mm, Hyward FC172--4700 |
| Transmission parameters | |||
| Gearbox Model: | Fast 10JSD180K | Number of gears: | 10 gears |
| Chassis parameters | |||
| Front/rear axle load: | 16/40 tons | Number of tires: | 10pcs |
| Tire specifications: | 13.00-25 | ||
