CCS1 CCS2 High Quality Niche Products Ethernet 4G DC Charger For Electric Car
Outdoor Fast Charging Electric Vehicle Charger 120kW 180kW Integrated Charger
APP Control 120kW DC EV Electric Vehicle Charging Station OCPP
Products Description:
Outdoor DC integrated charger adopts a new generation of intelligent charging module, single and double output can be arbitrarily selected according to customer requirements. The dual-gun type can be distributed according to the actual charging demand to meet the charging needs of small and medium-sized passenger cars and logistics vehicles.
A charging station, also called an EV charger or electric vehicle supply equipment (EVSE), is a piece of equipment that supplies electrical power for charging plug-in electric vehicles (including hybrids, neighborhood electric vehicles, trucks, buses, and others).
The charging station is composed of integrated chargers, high and low voltage power distribution, site layout design, monitoring video system and operation management system.
Features:
1) EV chargers: AC & DC charging piles, including 7kW, 120kw, 180kw.
2) Power distribution: 0.4kV low voltage distribution box, low voltage cable, cable bridge.
3) Communication system: Combined with the charging station access system solution, the charging station is connected to the external network and the internal network by the means of optical fiber networking, network cable networking, and connected to charging pile operation management system through wireless router or optic fiber router.
4)Video surveillance system: cloud platform camera ball, camera gun.
5)Operation management system: operation, management & monitoring of charging station is displayed at cloud platform.
6)Fire protection system: The distance between the building and the parking space should meet the fire protection requirements,the design of the entrance and exit of the site should meet the evacuation requirements of the parking lot, and the station should be equipped with fire fighting sand, dry powder fire extinguisher and fire alarm system.
Specification:
| Product | Integrated DC Chariging Station | |
| Type | DC-180KW | |
| Dimensions | 720*557*1700(mm) | |
| HMI(Human Machine Interface) | 7 inch touch screen | |
| AC Power | 380Vac±15% ; 50Hz±10% ; L1+L2+L3+N+PE | |
| Output Voltage | 150-1000VDC | |
| Output Current | CCS: 0 – 200A, CHAdeMO: 0 – 125A,3-phase 32A max | |
| Rating Current | 250-280A | |
| Output Power | 180KW | |
| Efficiency | ≥ 94% | |
| Power factor | ≥ 0.99 | |
| Work Condition | Elevation: ≤2000m; Temperature: -20°C~+50°C; | |
| Working humidity | 5% ~ 95% without condensation | |
| Charging Mode | Swipe card, scan code | |
| Networking Mode | Ethernet, 4G, wifi,mini program | |
| Operating Pattern | noncharge offline,charge offline, charge online | |
| Protection Function | Over voltge; under voltage; over load; short circuit; earth leakage; ground protection surge protection, etc. | |
| Charging standards | CCS-1/2, CHAdeMO | |
| Charging Cable Length | 5m (customizable) | |
| Protection Grade | Ip54 | |
If you are interested in our product, never hesitated to contact us!
