High Quliaty 120kW 180kW Dual Gun Type1 Type2 EV DC Charging Stations
Integrated Electric Vehicle DC 120kW 180kW EV Charger Electric vehicle Fast Charging Stations 80kW
DC 120kW 180kW EV Charger Electric vehicle Fast Charging Stations
Products Description:
This product is mainly composed of human-computer interactive touch screen, card reader, power metering module, charging module,communication module, charging interface, control module and pile body. The charging stake has multiple protection functions, and the input and output have double safety protection measures. When charging, the charging cable can be monitored in real time. When
the connection is abnormal, the charging can be terminated immediately to ensure the personal and vehicle safety during charging.
- The user-friendly interface display and control guide function make it easy for customers to complete the charging process.Provide a variety of communication interfaces, such as Ethernet, GPRS, to communicate with the monitoring center and the operation management center in real time, to monitor the charging status in real time.
- From R&D, production and manufacturing of equipment to investment, construction and operation of charging station.
- Participate in the formulation of charging standards to ensure the advancement and reliability of Technology.
- Separate and independent cloud monitoring platform for charging operation to ensure high efficiency of management.
- Perfect charging operation management system to ensure the safe operation of charging station.
Composition of charging station:
120-180kW Split Type Liquid Cooling DC super charging system.7”touch screen and HMI Interface support English, French, Russian and Spanish. Split Type design improve user comfort and save installation space. Liquid cooling and up to 280A output current.
Real-time status query, device information/power will show on the LCD screen.
1) EV chargers: AC & DC charging piles, including 7kVA, 30kw, 60kw.
2) Power distribution: 0.4kV low voltage distribution box, low voltage cable, cable bridge.
3) Communication system: Combined with the charging station access system solution, the charging station is connected to the external network and the internal network by the means of optical fiber networking, network cable networking, and connected to charging pile operation management system through wireless router or optic fiber router.
4)Video surveillance system: cloud platform camera ball, camera gun.
5)Operation management system: operation, management & monitoring of charging station is displayed at cloud platform.
6)Fire protection system: The distance between the building and the parking space should meet the fire protection requirements,the design of the entrance and exit of the site should meet the evacuation requirements of the parking lot, and the station should be equipped with fire fighting sand, dry powder fire extinguisher and fire alarm system.
Specification:
| Product | Integrated DC Chariging Station | |
| Type | DC-180KW | |
| Dimensions | 720*557*1700(mm) | |
| HMI(Human Machine Interface) | 7 inch touch screen | |
| AC Power | 380Vac±15% ; 50Hz±10% ; L1+L2+L3+N+PE | |
| Output Voltage | 150-1000VDC | |
| Output Current | CCS: 0 – 200A, CHAdeMO: 0 – 125A,3-phase 32A max | |
| Rating Current | 250-280A | |
| Output Power | 180KW | |
| Efficiency | ≥ 94% | |
| Power factor | ≥ 0.99 | |
| Work Condition | Elevation: ≤2000m; Temperature: -20°C~+50°C; | |
| Working humidity | 5% ~ 95% without condensation | |
| Charging Mode | Swipe card, scan code | |
| Networking Mode | Ethernet, 4G, wifi,mini program | |
| Operating Pattern | noncharge offline,charge offline, charge online | |
| Protection Function | Over voltge; under voltage; over load; short circuit; earth leakage; ground protection surge protection, etc. | |
| Charging standards | CCS-1/2, CHAdeMO | |
| Charging Cable Length | 5m (customizable) | |
| Protection Grade | Ip54 | |
If you are interested in our product, never hesitated to contact us!
