7kw AC EV Charging Station Cable 32A EV Charger Floor Mounted Charging Point for Home Use
Price:
$268.00/Pieces 1-99 Pieces
MOQ:
10
Delivery Time:
7-14Days
Brand:
Energy splendor
Product Description
Smart Home Ev Charger EASY USE Commercial EV Charging Station 32A EV Charger Level 2 Charging Station
Energy splendor is designed to provide a user-friendly solution for electric vehicle charging in various scenarios such as private residences. Urban areas, parking lots, department stores, gas stations, etc.
Our product line offers a variety of solutions, including slow charging (AC) and fast charging (DC).
The single-phase electronic energy meter is used for electrical metering, and communicates with the main control board through the theRS-485 interface;
Using a non-contact smart card reader, reading information about the IC card, communicating with the main control board through the RS-485 interface, and mastering
The board background program performs charger identity identification, user information recording, charging cost calculation, etc.; the line switch adopts a switch with leakage protection function and installs an emergency stop button;
The shape is made of sheet metal and part of ABS plastic structure.
This Commercial EV Charging Station allows you to charge your electric vehicle directly at home in an easy and safe way. Using the APP, you can even manage events remotely.
Energy splendor is committed to respecting the environment by focusing on resource use and conservation. We feel a responsibility to promote widespread electric mobility across the country and across generations.
Electric vehicles and charging infrastructure must be integrated into the urban environment to support lifestyles that live in harmony with the environment. Only then can we take this path and provide added value for everyone.
Q1: What are your terms of payment?
A: We will recommend our customer to use different terms of payment based on the difference in the quantity of order.
Q2: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q3:Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
Key Features
. Robust Protection
The charging pile has been equipped with robust protection functions of overload, surge, overvoltage, under-voltage, short circuit, earthing, overheat, lightening, emergency stop, etc to avoid damages by accident caused by abnormal weather or grid.
. Appearance with Perfect Sealing
Appearance design adopts zinc-plated board + multi-layer spraying process to achieve excellent sealing, which can resist the rainstorm effectively. The multi-layer spraying technology could prevent rust from causing damage to the product. Anti-ultraviolet treatment adopted in the coating process aims to restrain the cabinet from aging, which has ensured a longer life cycle of the product.
When to charge an electric car?
Contrary to what many believe, there is no need to wait until the car battery is fully discharged before charging it. For the latest generation lithium batteries installed in the most modern electric vehicles, the opposite is true, i.e. it is best to avoid dropping the charge too low, as the residual current level is closer to zero the higher it will be. The required charging effort. So-called "bottle feeding" in technical jargon in the EV world, a small, frequent partial charge is better. Therefore, those who own an electric car are better off charging it every time they park it in a garage or parking space.
specification
| Rated Current | 32A |
| Voltage | 380V |
| Connetor | Type 2 |
| Charging way | Plug and in |
| Output Power | 7KW |
| Waterproof | IP54 |
| Operating Temperature | -30~+50 C |
| Cable Length | 5m |
| Weight8 | 8kg |
| Packing way | Carton |
| Charging standard | EN IEC 62196 ,61851 |
| Certificate | CE TUV |
| Key Words | 62196 EV Charger |
| Warranty | 2 Year |
| Installation method | Wallbox |
| OEM | accept |
| capacity | 5000pcs/month |
