240V 16 Amp Mobile Electric Portable Ev Charging Station 3.5kW IP54 IP Grade High Strength Plastic
Electric Cars 16A 3.5KW Portable Electric Car Charger New Energy Car Charging Gun
16A 3.5KW Portable Electric Car Charger New Energy Car Charging Gun
Product Description:
Electric Vehicles (EVs) are the future. We applaud you for being ahead of the pack by making a wise, pioneering investment. The EV Charger can make EV use way easier by supplementing your factory-issued charger. It produces a rapid-fire charge and has LED indicator lights that notify you of any charging errors. 240V 16 Amp Level 2 EV Charger with plug . It is portable, easy to store, charges faster than a normal portable electric car chargers, and works with most electric vehicles. It can be used at NEMA 10-30 outlet or NEMA 6-20 outlet level 2 charger, special 220/240V electrical outlets. The charging station is rugged and robust, equipped with over voltage, overheat and over current protection. The indicating light on the charging station helps to show the various stages of charging and to warn of possible errors.
The suitable environment temperature of use is -30°C–+50°C, in the surrounding, no acid-base and other corrosive gas in order to avoid affecting product performance. Try to avoid in the directly rain or excessively high humidity environment and should try to prevent shell damage.
Features:
- 5 meter long charging cable for electric cars.
- 1-phase design and 16A current allows charging electric cars with a power of up to 3.6kW.
- Type 2 EV connector (Europe); and plug with safety class IP54 adapted to outdoor conditions.
- Due to its low weight, it is easy to transport.
- Excellent Protection: The portable level 2 charger features an intelligent chip to provide lightning / leakage / grounding / over voltage / under voltage / over charge / over current / overheat protection. With CE certification, IP65 control box and an IP54 EV connector to secure your car charging.
Specification:
| Product | AC Easy-use Charging Box(Plastic) |
| Type | AC-3.5KW |
| Dimensions | 324*139*342 |
| Voltage | 220V |
| AC power | 220Vac±20% ; 50Hz±10% ; L+N+PE |
| Rating Current | 16A |
| Power Output Rating | 3.5kW |
| Environmental | Altitude:≤2000m； Temperature:-20℃~50℃ |
| Charging Mode | Plug and Play |
| Weight | 3.2kg |
| Packing Way | Carton |
| Capacity | 20000pcs/month |
| Connector Type | SAE J1772(Type 1)/IEC 62196-2(Type 2) |
| Charging Cable Length | 5m (customizable) |
| Protection Grade | Ip54 |
WARNING
- Do not modify, retrofit, or change any EV Charging Cable Station's part by yourself under any circumstances
- Do not allow rain water to run along the length of charge cable, causing the electrical outlet or charging port to become wet.
- Make sure that Portable EV Charger Station all safety facilities are available at all times and test then regularly to ensure Safety
- Portable EV Charging Box's all metal parts should be insulated to prevent short circuit caused by the touch of the tool with the metal frame.
- The leakage protection would stop the charger working if it gets water into it, or even worse, cause the fire, electrical shock or serious injury.
- Regularly check whether the portable EV charger has visible damage, there may be an electric shock hazard when using the damaged product Package
