ISO9001 R670 10kw Inverter Gasoline Generator 15.9A Per Phase

Price Negotiable
Price: Negotiable
MOQ: 1 Set
Delivery Time: 7-15 work days
Brand: HUAN NENG
Product Description

10kw High Power petrol AVR Voltage Automatic Adjustment Gasoline Generator

10kw Gasoline Generator

THE BENEFIT:

• Powerful commercial grade V-twin engine, low vibration, low emission, more durable, more stable, more reliable and more powerful.

• Precise control of ignition, intelligent speed control according to load, not only fuel saving, but also economical and efficient;

• Short-circuit protection is more at home, safe, reliable and more effective;

• Humanized design concept, integrated panel operation, clearly visible and easy to operate.

• Well-designed commercial high-power generators, covering 110-415V, single/three-phase, minimize maintenance and upkeep costs.

• Equipped with safety protection system and large fuel tank to ensure long-term operation, continuous operation for 7 hours at rated power.

• Oil protection system, automatic alarm and shutdown for low oil level to prevent the engine from working under low oil level, giving the engine more protection.

• Omnidirectional movement of wheels, dragging, pulling and turning in one go, easy to achieve. •ATS automatic terminal is reserved, which can automatically start in case of unattended power failure

ADD: if you want to know more details, please contact us.

APPLICATION:It is used in farmland irrigation and drainage, as well as water supply and drainage in industrial and mining enterprises and cities and towns.



THE DETAILS

dynamo Unit Type BL13000W
Excitation method AVR voltage automatic adjustment
maximum output power 11KW
Rated output power 10KW
Rated voltage 230V 230V/400V
Maximum current 47.8A 15.9A per phase
Rated frequency 50HZ
Phase single phase three phase
power factor cos 1.00 0.8
Insulation class F级
engine engine model R670
Rigid x stroke 78x70mm
Displacement 670cc
fuel consumption rate ≤374g/KW.h
ignition method compression ignition
engine type V-twin/in-line twin, four-stroke, water-cooled, direct injection
fuel type Diesel: 90#↑
oil quantity 1.5 L
Start method Electric start
Attachment configuration fuel capacity 25L
battery capacity 12V-32AH maintenance-free battery
oil alarm yes
fuel indicator yes
control panel digital display
Caster attachment Standard
other noise 70Dba/7m
Continuous working time 8h
Dimensions 1140*655*930
weight 210KG
