W2.15 Single Cylinder Vertical Shaft Diesel Engine 385*420*450mm
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
7-15 work days
Brand:
HUAN NENG
Product Description
HN178 Four-Stroke Air-Cooling Vertical Direct Injection Diesel Engine
Air-Cooled Diesel Engine
Advantage,
1. Our engines have many patents, high product performance, and cooperation with domestic and foreign institutions of higher learning
2. light design, compact result, high output power in the same volume, can meet a variety of applications
The Details of this diesel engine
| 型号 Model | HN173FB | HN178F | HN186FA | HN188FA | HN192F | HN195F |
| 类型 type | 单紅,四沖程,风冷,立式' 直原式 | |||||
| 燃烧系统 Combustion system | 直喷 | |||||
| 缸径X行程 The cylinder diameter x Trip | 73x59 | 78x62 | 86x72 | 88x75 | 92x75 | 95x75 |
| 排量(L) Displacement | 0.247 | 0.296 | 0.418 | 0.45€ | 0.499 | 0.532 |
| 压缩比 Compression Ratio | 20:1 | 20:1 | 19:1 | 20:1 | 19:1 | 19:1 |
| 發定功率/转速(Kw/rpm ) Rated Power/speed | 3.2/3000,3.6/3600 | 3.7/3000.4.0/3600 | 5.8/3000,6.6/3600 | 6.6/3000.7.5/3600 | 7.5/3000,8.2/3600 | 8.5/3000,9.2/3600 |
| 最大功率/转速(Hp/rpm ) Max Power/Speed | 4.3/3000,4.8/3600 | 5.0/3000,5.5/3600 | 7.9/3000,9.0/3600 | 9.0/3000,10.2/3600 | 10.2/3000,11.2/3600 | 10.2/3000,11.2/3600 |
| 额定转速 Rated Speed | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 |
| 启动方式 Start The Way | F:手启动 E:电启动 F: Manual start e: electric start | |||||
| 油箱容积(L) Tank Volume | 2.5 | 3.5 | 5.5 | 5.5 | 5.5 | 5.5 |
| 润滑油容员(L ) Lubricating Oil Capacity | 0.75 | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 |
| 油耗(L/H) Fuel Consumption | w1.2 | W1.41 | W2.15 | w2 | w2 | w2 |
| 燃油牌号 Fuel Brand | 柴油:0# (§) , -10# (冬) Diesel: 0 x 10 (summer), - 10 x 10 (winter) | |||||
| 润滑油牌号 Lubncating Oil Brand | SAE10W30 (CD级以上) Sae10w30 (above CD level) | |||||
| 外型尺寸LXWXH ( mm ) Dimensions | 332x376x415 | 385x420x450 | 420x440x495 | 420x440x495 | 420x440x495 | 420x440x495 |
| 净車(kg) The Net Weight | 手启动:28电启动:32手启动:33电启动:38 Manual start: 28 Manual start: 33 Electric start: 32 Electric start: 38 | 手启动:47电启动:53手启动:48电启动:53 Manual start: 47 Manual start: 48 Electric start: 53 Electric start: 53 | 手启动:50电启动:55 Manual start: 50 Electric start: 55 | 手启动:50电启动:55 Manual start: 50 Electric start: 55 | ||
