V Twin Open Frame 3 Phase Mobile Generator Compression Ignition 10KW
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
7-15 work days
Brand:
HUAN NENG
Product Description
10KW Equivalent Power Mobile Open Frame Diesel Generator
Equal power 10KW Diesel Generator
THE ADVANTAGE :
1. Stronger, more stable, reliable, more powerful commercial V-twin engine with less vibration and less emissions.
2. 110-415V, single-phase/three-phase capacity, high-performance commercial generator designed to minimize maintenance and service costs.
ADD: if you want to know more details, please contact us.
| dynamo | Unit Type | BL12500CJ | |
| Excitation method | AVR voltage automatic adjustment | ||
| maximum output power | 11KW | ||
| Rated output power | 10KW | ||
| Rated voltage | 230V | 230V/400V | |
| Maximum current | 47.8A | 15.9A per phase | |
| Rated frequency | 50HZ | ||
| Phase | single phase | three phase | |
| power factor cos | 1.00 | 0.8 | |
| Insulation class | F级 | ||
| engine | engine model | EV80/292 | |
| Rigid x stroke | 86*72mm/92*75mm | ||
| Displacement | 840cc/997cc | ||
| fuel consumption rate | 270g/KW.h | ||
| ignition method | compression ignition | ||
| engine type | V-twin/in-line twin, four-stroke, water-cooled, direct injection | ||
| fuel type | Diesel: 0# (summer)-10# (winter)-35# (severe cold) | ||
| oil quantity | 1.7L/2.6L | ||
| Start method | Electric start | ||
| Attachment configuration | fuel capacity | 25L | |
| battery capacity | 12V-36AH maintenance-free battery | ||
| oil alarm | yes | ||
| fuel indicator | yes | ||
| control panel | digital display | ||
| Caster attachment | Standard | ||
| other | noise | 70Dba/7m | |
| Continuous working time | 8h | ||
| Dimensions | 1160*660*900 | ||
| weight | 240KG | ||
