24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V
24V 15A Universal Automotive Relay Lightweight 4 Pin SPST Relay MQ8-A-S-DC24V
Universal Automotive Relay Description:
MQ8 series relays are widely used for automotive products, small in size, safe and reliable, long-lasting, perfectly compatible with G8QNxxx of Omron, HFKWxxx of Hongfa,895xxx of Songchuan, etc.
Universal Automotive Relay Feature:
1. Durable, safe, and reliable
2. Low coil power 0.36W / 0.6W
3. Small size, lightweight
4. Widely used for fan control, car flame glowplug, car horn, etc.
Universal Automotive Relay Name rule :
MQ8 - C -S -DC12V
1. Model No.
2. Contact Form: A: Normally open B: Normally Close C: Normally open & close
3. Construction: S: Sealed type E: Flux tight type
4. Normal Coil Voltage: 5,6,9,12,18,24(DC)
Universal Automotive Relay Coil Rating:
| No. | Coil Voltage(VDC) | Coil ResistanceΩ±10% | Pick up (VDC) Max. (75% of Rated Voltage) | Drop out (VDC) Min. (10% of Rated Voltage) | Power (W) | Operate Time (ms) | Release Time (ms) | |
| Rated | Max. | |||||||
| 005-250 | 5 | 5.5 | 42 | 3.5 | 0.5 | 0.6 | ≤10 | ≤5 |
| 006-250 | 6 | 6.6 | 60 | 4.2 | 0.6 | |||
| 009-250 | 9 | 9.9 | 135 | 6.3 | 0.9 | |||
| 012-250 | 12 | 13.2 | 240 | 8.4 | 1.2 | |||
| 024-250 | 24 | 26.4 | 960 | 16.8 | 2.4 | |||
| 005-540 | 5 | 5.5 | 31 | 3.5 | 0.5 | 0.8 | ≤10 | ≤5 |
| 006-540 | 6 | 6.6 | 45 | 4.2 | 0.6 | |||
| 009-540 | 9 | 9.9 | 101 | 6.3 | 0.9 | |||
| 012-540 | 12 | 13.2 | 180 | 8.4 | 1.2 | |||
| 024-540 | 24 | 26.4 | 720 | 16.8 | 2.4 | |||
