12 Volt 5 Amp Mini PCB Mount Relay RJ - SS - 112LM For Car Flasher Controller
12 Volt 5 Amp Mini PCB Mount Relay RJ - SS - 112LM For Car Flasher Controller
PCB Mount Relay Description:
NBC 922 series automotive relay,5-48V input voltage, maximum current reach 20A, small size, low coil power consumption,1.5KV dielectric withstand voltage between coil and contact,environmental-friendly and PCB board mounting directly, very fit the automotive industry, sound equipment, automatic system, etc. Products are approved by TUV/CQC/UL safety system testing, reliable and safe.
PCB Mount Relay Features:
1. safe and sensitive
2. coil insulation class A
3. 0.2W for coil power
4. flux-resistance
5. anti-explosion type for option
PCB Mount Relay Specification:
| Coil data: | |||||||||
| Coil input voltage | 5/9/12/24VDC | ||||||||
| Coil power | D type:450mW,L type:200mW | ||||||||
| Response voltage | ＞75％(Room temp.) | ||||||||
| Drog out voltage | ＜5％(Room temp.) | ||||||||
| Operating time / Release time | Less than 8ms/Less than 5ms | ||||||||
