Ultra Slim PCB Mount Relay 24V 6A SPDT 0.17W 4KV RSA - 105D For Microwave
Ultra Slim PCB Mount Relay 24V 6A SPDT 0.17W 4KV RSA-105D For Microwave
PCB Mount Relay Description:
NBC 922 series automotive relay,5-48V input voltage, maximum current reach 20A, small size, low coil power consumption,1.5KV dielectric withstand voltage between coil and contact,environmental-friendly and PCB board mounting directly, very fit the automotive industry, sound equipment, automatic system, etc. Products are approved by TUV/CQC/UL safety system testing, reliable and safe.
PCB Mount Relay Features:
1. ultra-thin,6mm width only, saving space
2. rated current 6A
3. 1 Form C, SPDT,5pins
4. IP67 protection grade
5. base match with it carry LED and protection circuit
PCB Mount Relay Specification:
| Technical Ratings | |
| Insulation Resistance: | 100MΩ |
| Dielectric Strength(Between coil&contact): | 1500VAC |
| Operate Time (Max.): | 15ms |
| Release Time (Max.): | 5ms |
| Ambient Temperature: | -40℃ ~ 85℃/105℃ |
| Terminal Type: | THT |
