Polished Pure Molybdenum Stirring Rod For Rare Earth Smelting Industry

Price Negotiable
Price: $50~80/kg
MOQ: 1kg
Delivery Time: 7~10 work days
Brand: PRM
Product Description

Molybdenum Rod Molybdenum Stirring Rod Is Used In Rare Earth Smelting Industry



1. Introduction Of Molybdenum Rod Mo Stirring Rod:



The molybdenum stirring rod used in the rare earth industry is usually made of high-purity molybdenum material, which has good high temperature corrosion resistance and mechanical strength. Its structure is mainly composed of a steel bottom and a molybdenum stirring rod, which are connected by a special connection method to ensure the overall stability and reliability of the stirring rod. This product is widely used in high temperature and highly corrosive environments in rare earth smelting, which can effectively improve the efficiency and quality of rare earth smelting.



2. Size Of Molybdenum Rod Mo Stirring Rod:



Diameter 10~40mm
Length 500~200mm
Purity >99.95%
Density 10.22g/cm3
Standard ASTM B387
Elongation

≥10%

Tensile strength

610 Mpa

Material Composition

Mo,TZM,Mo-La





3.Production Process Of Molybdenum Rod Mo Stirring Rod:



Sintered

molybdenum

rod

No. Production Process Equipment Quality inspection point
1 Mo powder(Raw material)

1. Mo powder purity

2. Molybdenum powder FSSS after batching

2 Sieve High frequency vibrating screen
3 Mix powder V-shaped mixer
4 Inspect
5 Isostatic pressing Isostatic pressing

1.Dimensions

2.Single weight

3.Surface Quality

6 Inspect
7 Intermediate frequency sintering Intermediate frequency induction sintering furnace

1.Dimensions,single weight,density

2.Straightness

3.Surface quality

8 Straightening straightening machine
9 Inspect
10 Package
  No. Production Process Equipment Quality inspection point
1 Sintered molybdenum rod

1. Density

2.Dimensions

3.Straightness

4.Surface quality



2 Forging Rotary forging equipment or forging air hammer
3 Machining lathes, grinders, etc.
4 Inspect
5 Package



4. The advantages of molybdenum stirring rods used in the rare earth industry mainly include:



Good high temperature corrosion resistance: In the process of rare earth smelting, it is necessary to deal with corrosive substances such as strong acid and strong alkali, so the stirring rod must have good corrosion resistance. Molybdenum has good corrosion resistance and can withstand the erosion of corrosive substances such as strong acid and strong alkali. Therefore, molybdenum stirring rods used in the rare earth industry have excellent high temperature corrosion resistance.



High mechanical strength: The rare earth smelting process requires high-intensity stirring operations, so the stirring rod must have good mechanical strength. Molybdenum has excellent mechanical strength and can maintain good stability and durability in harsh environments such as high temperature, high pressure, strong acid, and strong alkali. Therefore, molybdenum stirring rods for rare earth industries have excellent mechanical strength.



Good wear resistance: A large amount of particles and oxides will be produced in the rare earth smelting process, so the stirring rod must have good wear resistance. Molybdenum has good wear resistance, which can reduce wear and prolong service life during high-speed stirring, so molybdenum stirring rods used in the rare earth industry have excellent wear resistance.



Reasonable design and excellent manufacture: the design and manufacture of molybdenum stirring rods for the rare earth industry need to take into account its use characteristics in high temperature and strong corrosive environments, so it must be designed and manufactured in strict accordance with relevant standards to ensure its stability and reliability . At the same time, high-quality raw materials and precise processing techniques need to be used in the manufacturing process to ensure the high quality and good performance of the product.



To sum up, molybdenum stirring rods for the rare earth industry have the advantages of good high temperature corrosion resistance, high mechanical strength, good wear resistance, reasonable design, and excellent manufacturing. They are one of the indispensable and important equipment in the rare earth smelting process.
