99.95% RO4200 RO4210 RO4251 RO4261 Niobium Plate Niobium Zirconium Alloy Plate
Niobium Plate Niobium Zirconium Alloy Plate
1. Information Of Niobium Plate Niobium Zirconium Alloy Plate:
Niobium plate
Purity:99.95%
Density: 8.57 g/cm3
Thickness : min. 0.1 mm
As per ASTM B393
Grade: RO4200 RO4210 RO4251 RO4261(Nb-Zr)
Delivery status: Annealed
Chemical content:
| Chemical Element (weight %, max.) | |||||||||||||||
| Grade | C | O | N | H | Ta | Fe | Ti | W | Hf | Al | Mo | Si | Ni | Zr | Nb |
| RO4200 | 0.01 | 0.015 | 0.01 | 0.0015 | 0.1 | 0.005 | 0.02 | 0.03 | 0.02 | 0.0002 | 0.01 | 0.005 | 0.005 | 0.02 | Remain |
| RO4210 | 0.01 | 0.025 | 0.01 | 0.0015 | 0.3 | 0.01 | 0.03 | 0.05 | 0.02 | 0.005 | 0.02 | 0.005 | 0.005 | 0.02 | Remain |
| R04251 | 0.01 | 0.015 | 0.01 | 0.0015 | 0.1 | 0.005 | 0.02 | 0.03 | 0.02 | 0.0002 | 0.01 | 0.005 | 0.005 | 0.8~1.2 | Remain |
| R04261 | 0.01 | 0.025 | 0.01 | 0.0015 | 0.5 | 0.01 | 0.03 | 0.05 | 0.02 | 0.005 | 0.05 | 0.005 | 0.005 | 0.8~1.2 | Remain |
Tolerance of Niobium plate:
2. Mechanical Performance of Niobium Plate:
3. Application of Niobium Plate:
Superconducting technology: Niobium is a key material in the production of superconducting magnets and superconducting radiofrequency (SRF) cavities. Niobium plates are used to manufacture the superconducting radiofrequency cavities in particle accelerators like those at CERN and in advanced medical and scientific instruments.
Aerospace and aviation: Niobium is used in aerospace applications, such as in the manufacturing of high-temperature, corrosion-resistant parts, jet engines, and space exploration equipment. Niobium plates can be used in the construction of rocket nozzles and other critical components.
Chemical processing: Niobium's exceptional corrosion resistance makes it suitable for use in equipment and components in the chemical industry. Niobium plates are used for manufacturing vessels, heat exchangers, and pipes that come into contact with aggressive chemicals.
Electronics: Niobium is employed in the production of capacitors, which are widely used in electronics. Niobium oxide capacitors offer excellent performance and reliability, and niobium plates are a key component in their construction.
Medical implants: Niobium is biocompatible and resistant to corrosion, making it suitable for use in medical implants such as bone screws, dental implants, and other surgical instruments. Niobium plates can be used to manufacture these components.
Nuclear reactors: Niobium can be used in nuclear reactors for its resistance to high-temperature and radiation. Niobium plates are used in reactor components like pressure vessels and control rods.
Semiconductors: Niobium is used in the semiconductor industry to make Josephson junctions and other specialized devices.
Research and development: Niobium plates are used in various research applications and experimental setups due to their unique properties, including superconductivity and high-temperature stability.
