HEAT 205 Dingzun Cable 378/0.08 Super Fine Wire FEP Insulated High Temperature Wire For Lighting
Y-07
Details:HEAT 205
Description: 378/0.08 ultra fine wire
Conductor: tinned copper
Construction: 378/0.08
Insulation FEP
Rated temperature: 200 degree
Rated Voltage: 600V
Very thin wires can be welded with an electric iron by hanging tin. If it is a multi-strand wire, you can expose a part of the two wire heads, stick the exposed part on the solder paste, and then heat the electric iron, after heating the electric iron, melt the solder wire. Solder the wire head. Solder both ends. Then, the two wires are fitted together, and the two wires are welded together with a soldering iron tip hung with solder. Then seal the welded area with the appropriate heat shrink tube.
|
conductor Cross -sectional(mm²) |
Conductivity (No./mm) |
Nominal insulation thickness (mm) |
Cores |
Shielding thickness(mm) |
Sheet thickness (mm) |
20℃Conduct DC resistance (≤Ω/km) |
|
| Tin -plated copper | Silver -plated copper | ||||||
| 0.035 | 7/0.08 | 0.15 | ≤37cores | ≥0.2 | ≥1.0 | 568 | 525 |
| 0.05 | 7/0.10 | 0.20 | 356 | 330 | |||
| 0.08 | 7/0.12 | 0.20 | 245 | 227 | |||
| 0.12 | 7/0.15 | 0.25 | 160 | 146 | |||
| 0.20 | 7/0.20 | 0.25 | 90.4 | 83.5 | |||
| 0.35 | 19/0.16 | 0.25 | 53.1 | 49.5 | |||
| 0.50 | 19/0.18 | 0.25 | 36.7 | 36.0 | |||
| 0.75 | 19/0.23 | 0.28 | ≤19cores | ≥1.2 | 24.6 | 22.7 | |
| 1 | 19/0.26 | 0.28 | 20.4 | 19.0 | |||
| 1.5 | 19/0.32 | 0.32 | 12.7 | 11.7 | |||
| 2 | 19/0.37 | 0.32 | 10.0 | 9.45 | |||
| 2.5 | 19/0.41 | 0.40 | 7.43 | 6.86 | |||
| 4 | 37/0.37 | 0.40 | ≤7cores | ≥1.5 | 4.88 | 4.51 | |
| 6 | 37/0.45 | 0.50 | 3.30 | 3.05 | |||
