Z-30

Details:HEAT 180

Description: UL3135 SILICONE WIRE
Conductor: 16awg 273/0.08
Insulation: Silicone
Rated temperature: -60℃---+200℃
Rated Voltage: 600V
TYPE: SILICONE WIRE
Certificate: UL3135

UL3239 silicone wire and UL3135 silicone wire have passed UL certification and are in line with EU environmental protection standards. The rubber material and copper wire have passed SGS test report. Not only high voltage resistance, but also high temperature (low temperature) resistance, acid and alkali resistance, aging resistance, long service life and other excellent performance. UL3239 silicone wire and UL3135 silicone wire insulation layer is silicone rubber, high temperature resistance is +150 degrees 200 degrees, flame retardant is also VW-1. The main difference is that the voltage resistance is not the same, UL3135 silicone wire rated voltage is 600V, and 3239 silicone wire for high voltage silicone wire, voltage is 3KV, 6KV, 10KV, 20KV, 30KV, 40KV, 50KV, the higher the voltage the thicker the insulation layer, the greater the outer diameter.
