China DX51D SGCC SPGC Galvanized Steel Sheet 4ft X 8 Ft 0.1 - 3mm Thickness for sale

DX51D SGCC SPGC Galvanized Steel Sheet 4ft X 8 Ft 0.1 - 3mm Thickness

Price Negotiable

Price: Negotiable

MOQ: 200kg

Delivery Time: 7-15 days

Brand: TISCO

Product Description

— Galvanized Sheet Metal —

What is hot dipped galvanized sheet?

Hot-dip galvanizing is a process of coating steel with a thin zinc layer, which serves as a barrier between the steel and the environment. The finish is applied by passing the steel through a molten bath of zinc at a high temperature.
The galvanized steel plate is covered with aluminum-zinc alloy on the surface of the steel plate. It is composed of 55% aluminum, 43.4% zinc and 1.6% silicon solidified at a high temperature of 600 ° C. Its entire structure is composed of aluminum-iron-silicon-zinc, forming a dense An alloy-coated steel sheet of quaternary crystal.

Galvanized sheet is refers to the surface has a layer of zinc plated steel plate.

Galvanized is a frequently used economic and effective anticorrosion method, about half of the zinc production in the world are used in this process.
Galvanized steel is regular steel sheets that have been coated in zinc to make them corrosion resistant. Regular steel is made of iron which will rust when exposed to moisture, either in the form of rain or ambient humidity. Over time rust will corrode a steel part to the point of failure.

Name	zinc galvanized steel sheet
Standard	AISI,ASTM,GB,JIS
Material	SGCC,SGCH,G550,DX51D,DX52D,DX53D
Brand	Shandong Huazhu Steel
Thickness	0.3-2.5mm
Width	1000mm-1500 mm
Tolerance	+/-0.02mm
Zinc coating	40-275g/m2
Surface treatment	Unoil,dry,chromate passivated, non-chromate passivated
Spangle	Regular spangle,minimal spangle, zero spangle,big spangle
Technique	Hot rolled, cold rolled
Package	Standard seaworthy export packing: 3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock, with inner coil sleeve
Description	Galvanized steel is mild steel with a coating of zinc. The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel. Zinc steel is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion
Remarks	Insurance is all risks and accept the third party test

STEEL GRADE	CHEMICAL COMPOSITION %					MECHANIC PROPERTY			C.B OF COATING
STEEL GRADE	C	Si	Mn	S	p	T.S	Y.S	E.L	C.B OF COATING
	x103	x103	x102	x103	x103	Mpa	Mpa	%	d=180
JIS G3302 SGCC	12	30	41	31	21	480	300	13	OK
JIS G3302 SGCH	12	10	21	18	6	680	650	20	OK
ASTM 653 CS.B	29	30	60	35	30	386	250-380	20	OK
DX51D+Z	20	21	18	1.8	11	355	245	38	OK
G550	12	6	73	5	17	715	654	8	OK
