Hot Rolled Galvanized Steel Strip DX52D DX53D DX54D DX55D Z40 Z60 Z80 Z100 Z180 Z275
Hot Galvanized Steel Strip DX51D DX52D DX53D DX54D DX55D Z40 Z60 Z80 Z100 Z180 Z275
Description
The galvanized steel strip undergoes a hot-dip galvanization process, wherein the steel strip is immersed in a bath of molten zinc. This process creates a protective zinc coating on the surface of the steel strip, imparting excellent corrosion resistance and durability.
DX51D, DX52D, DX53D, DX54D, and DX55D are all commonly used steel grades in the galvanized steel strip industry. Each grade has its own unique composition and characteristics that make it suitable for specific applications.Galvanized Steel Strip (DX51D, DX52D, DX53D, DX54D, DX55D) finds applications in a wide range of industries such as construction, automotive, appliances, and manufacturing. It is commonly used for roofing materials, structural components, ductwork, electrical enclosures, and more.
|
Standard
|
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
|
|
Steel Grade
|
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement |
|
Type
|
Coil/Sheet/Plate/Strip
|
|
Thickness
|
0.12-4.00mm,or customer's requirement
|
|
Width
|
600mm-1500mm, according to customer's requirement
|
|
Type of Coating
|
Hot Dipped Galvanized Steel(HDGI)
|
|
Zinc Coating
|
30-275g/m2
|
|
Surface Treatment
|
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
|
|
Surface Structure
|
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
|
|
ID
|
508mm/610mm
|
| Chemical Composition | ||||||
| GRADE | C | Si | Mn | P | S | Ti |
| SGCC/DX51D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| DX52D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| SGCD/DX53D+Z | ≤0.10 | ≤0.30 | ≤0.50 | ≤0.05 | ≤0.030 | ≤0.020 |
| SGCE/DX54D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| DX56D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| Structural | ≤0.20 | ≤0.60 | ≤1.70 | ≤0.10 | ≤0.045 | |
Details
Packing&Delievery
Our certifications
Our Warehouse
FAQ
1.Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge.but the customers have to pay the sample courier cost.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3.What can you buy from us?
Seamless Pipe,Precision Steel Pipe,Galvanized Pipe,Steel Plate,etc.
