Hot Dip Galvanized Steel Sheet Gi Sheet Metal SGCC Zinc40-275 Coated Steel
Factory Supplier Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Plate Sgcc
Product Description:
|
Product name
|
Zinc40-275 Coated Steel Hot Dip Galvanized Steel Sheet Plate Sgcc
|
|||
|
Standard
|
ASTM,DIN,JIS,BS,GB/T,GB,EN
|
|||
|
Material
|
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
|
|||
|
Application
|
galvanized steel coil is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion.
|
|||
|
Thick
|
0.12-4.0 mm / BWG / AWG or as your request
|
|||
|
Width
|
20-1500 mm or as your request, Normal width is 914/1000/1219/1250/1500 mm
|
|||
|
Zinc Coating
|
30~600 G/M2
|
|||
|
Surface Structure
|
Regular spangle,Minimum spangle, Zero spangle, Big spangle
|
|||
|
Surface Treatment
|
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) , Chromated/Non-Chromated, Oiled/Non-oiled, Skin pass
|
|||
|
Package
|
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
|
|||
|
Description
|
Galvanized steel coil is mild steel with a coating of zinc. The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel.
|
|||
| Chemical Composition | ||||||
| GRADE | C | Si | Mn | P | S | Ti |
| SGCC/DX51D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| DX52D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
| SGCD/DX53D+Z | ≤0.10 | ≤0.30 | ≤0.50 | ≤0.05 | ≤0.030 | ≤0.020 |
| SGCE/DX54D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| DX56D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
| Structural | ≤0.20 | ≤0.60 | ≤1.70 | ≤0.10 | ≤0.045 | |
Product Details
galvanized steel coil is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion.
Applications
Packing
Shipping
Our certifications
Factory Environment
FAQ
Q1: Are you trading company or manufacturer ?
A: We are a professional manufacturer with 50 years' experience and have took part in trading for 20 years.
Q2: How about your quality and how do you guarantee the quality?
A: All products we supply is primary as you need, Our company is certificated to ISO9001:2008, and every product will be tested
for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.
Q3: Do you provide samples ? Is it free or extra ?
A: Yes, we could offer the sample for free charge but freight cost shall be paid by your Party.
